TRENDnet TI-XPG102 10-Port Industrial EN 50155 M12 Gigabit PoE+ Railway Switch

TRENDnet TI-BG5091 10-Port M12 Gigabit PoE+ Unmanaged Railway Switch, Wall Mount

TRENDnet’s TI-XPG102 10-Port Industrial EN 50155 M12 Gigabit PoE+ Railway Switch has eight M12 gigabit PoE+ ports, two M12 gigabit ports, and one M12 power port with a total PoE budget of up to 200W with 56VDC input. This M12 Ethernet switch is equipped with an IP40 rated metal enclosure, designed to withstand a high-degree of vibration and shock, while operating within an extreme temperature range of -40° - 75° C (-40° - 167° F) for industrial EN 50155 applications. The M12 Ethernet switch is designed and tested for bus, train, automobile, and telecom applications.

Key Features

• 8x M12 (X-code) Gigabit PoE+ ports
• 2x M12 (X-code) Gigabit port with Bypass function
• 1x M12 (A-code) power port
• PoE power budget: 200W @ 56V DC / 100W @ 24V DC
• EN 50155 compliant for rolling stock and railway applications
• Hardened IP40 rated metal housing
• 20Gbps switching capacity
• Operating temperature range of -40° - 75° C (-40° - 167° F)
• M12 cables sold separately (models: TI-CD02, TI-CD05, TI-CP02)
• Power supply sold separately (model: TI-S24052)
• NDAA / TAA compliant (U.S. and Canada only)
• Lifetime Warranty

In the Box

1. TI-XPG102
2. Quick Installation Guide
3. Wall mount

Count on the TI-XPG102 Gigabit PoE+ Railway Switch for high-performance and dependability. Get more information about this switch and other networking devices by speaking with a network specialist at Westward Sales today.
