TRENDnet TI-S24052 240-Watt AC to DC DIN-Rail Power Supply, 52V Output

New TRENDnet TI-S24052 240W Industrial DIN Rail Power Supply, PFC, 52V Output
Model: TI-S24052
Availability: Normally in Stock
Standard Shipping & Handling
Qty: Add to Cart

TRENDnet TI-S24052 240-Watt DIN-RAIL AC to DC Power Supply with PFC, 48-56V Output

TRENDnet’s TI-S24052 AC to DC Industrial DIN-Rail Power Supply with PFC Function supplies up to 240W (52V DC, 4.61A) of power to industrial equipment, such as PoE switches, injectors, and WiFi access points. This industrial power supply supports active PFC to help eliminate unusable reactive power, and comes with an integrated DIN-Rail mount. It also supports protections for overload, short circuit, over voltage, over current, and over temperature. The industrial power supply is designed for industrial environments with an operating temperate range of -25° - 70° C (-13° - 158° F).

Key Features

  • Industrial power supply with integrated DIN-Rail mount
  • Provides up to 240W of power (52V DC, 4.61A)
  • Supported output voltage 48 – 56V DC
  • High efficiency 94% and low power dissipation
  • 150% peak load capability
  • Built-in active Power Factor Controller (PF > 0.98)
  • Cooling by natural air convection
  • Protections: Overload, short circuit, over power, over voltage, over current, over temperature
  • UL 508 approved
  • Built-in DC OK relay contact
  • -25° – 70° C (-13° – 158° F) wide operating temperature range
  • NDAA / TAA compliant (U.S. and Canada only)
  • 1-year warranty

NOTE: A power cord is not included and sold separately. Order the AC power cord at PWRCORD-NOPLUG (or see Product Accessories tab). The PWRCORD-NOPLUG has 3 stripped 18 AWG wires that screw into the TI-S24052 terminal blocks.

Technology
CategoryPower Supply
Power
Rated Power240 Watts
Output Voltage52 VDC
Input Voltage90 to 264 VAC | 127 to 370 VDC
Overload ProtectionYes
Mechanical
Weight844g (1.86 lb.)
Dimensions63 × 124 × 114mm (2.5 x 4.9 x 4.5 in.)
Ratings
Operating Temperature-25° - 70° C (-13° - 158° F)
Humidity90% non-condensing
CertificationsCE, FCC, UL 530470, CB IEC 62368
Safety StandardsUL508
MTBF200,000 hours @ 25° C
Warranty1 Year
Download NameFile Size
TRENDnet TI-S24052 Datasheet518.77KB
ImageModelProduct NamePrice
PWRCORDAntaira PWRCORD AC Power Cord$8.00Add to Cart
Tags: TI-S24052
