TRENDnet TI-BF22SFP 2-Port Industrial SFP to Gigabit PoE++ Media Converter

TRENDnet TI-BF22SFP Industrial Gigabit SFP Media Converter, IP30, DIN rail or wall mount
Model: TI-BF22SFP
Availability: Normally in Stock
Standard Shipping & Handling
Qty: Add to Cart

TRENDnet TI-BF22SFP Gigabit SFP to Gigabit PoE++ Media Converter, DIN-Rail/Wall Mount

TRENDnet’s TI-BF22SFP 2-Port Industrial SFP to Gigabit PoE++ Media Converter converts two long distance fiber connections to copper connections, while providing power to PoE, PoE+, and PoE++ compliant devices, such as IP cameras, VoIP phones, and wireless access points. With an operating temperature range of -40° - 75 °C (-40° -167 °F), the industrial PoE++ fiber media converter features a hardened IP30 rated metal housing suitable for tough, industrial environments. The industrial PoE++ fiber media converter’s rugged design also provides protection from shock, freefall, and vibration.

The TI-BF22SFP includes DIN-Rail mount and wall mount hardware.

Key Features

  • 2 x Gigabit SFP ports
  • 2 x Gigabit PoE++ RJ-45 ports
  • Hardened IP30 rated metal housing
  • Provides up to 90W for PoE, PoE+ and PoE++ compliant devices
  • Includes DIN-Rail and wall mounts
  • Extreme operating temperature range -40° - 75° C (-40° - 167° F)
  • Overload current protection
  • Powers supply sold separately (model TI-S15052)
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty

In the Box

  1. TI-BF22SFP
  2. Removable terminal block
  3. DIN-Rail and wall mount kit
Technology
CategoryMedia Converter
Media Converter TypeFiber to Gigabit Ethernet
Total Ports4
Ethernet Ports2 Gigabit (10/100/1000TX)
Fiber Ports2 x Gigabit SFP ports
Fiber InterfaceSFP Slot
StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Jumbo Frame Support16KB
MAC Table Size1K
Power
Power Consumption3.84W (without PoE) @ 48V DC
Connection4-pin terminal block
Input Voltage48 - 56V DC
Surge ProtectionYes
Mechanical
EnclosureIP30 Metal case
MountingDIN Rail, Wall Mount
Shock / VibrationShock (IEC 60068-2-27), Freefall (IEC 60068-2-32), Vibration (IEC 60068-2-6)
Weight176g (6.2 oz.)
Dimensions104 x 81.5 x 32mm (4 x 3.2 x 1.2 in.)
Ratings
Operating Temperature-40° - 75° C (-40° - 167° F)
Humidity95% non-condensing
RoHS CompliantYes
CertificationsCE, FCC
MTBF551,468 hours
WarrantyLifetime
Download NameFile Size
TRENDnet TI-BF22SFP Datasheet1.08MB
