TRENDnet’s TEG-284WS Gigabit Web Smart Switch offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of SMB networks. This rack mountable IPv6-ready managed switch comes with an intuitive web-based interface. Advanced managed switch features include LACP to increase bandwidth between switches by grouping ports together, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this a powerful solution for any SMB network. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with an easy-to-use voice VLAN feature.
Free up router resources by offloading routing processes to this managed switch by using the L2+ IPv4/IPv6 static routing feature to efficiently route traffic at the switch level. The dynamic ARP inspection feature helps protect connected devices from man-in-the-middle attacks by discarding malicious and invalid ARP packets. Take advantage of the available multicast and IGMP/MLD snooping features to optimize IP surveillance system performance, and minimize network traffic. TRENDnet’s web smart managed switch provides twenty four gigabit ports, four shared Gigabit ports (RJ-45 or SFP), a 40Gbps switching capacity, a built-in power supply, and rackmount brackets.
TRENDnet Hive is a cloud management platform that provides a centralized cloud-based, remote network management solution for TRENDnet network devices. The TRENDnet Hive cloud networking solution offers better overall visibility of your network devices from a single intuitive and easy-to-use cloud interface. Advanced features supported with the Hive cloud networking solution include event and device hardware monitoring, traffic statistics, notification alerts, and troubleshooting tools. With the TRENDnet Hive network cloud manager, network device provisioning can be more easily accomplished through scheduled or immediate deployment of batch firmware and configuration updates. Reduce the time, complexity, and management costs of your network with the reliable TRENDnet Hive cloud networking solution.
Easily manage and configure the TEG-284WS Managed Switch remotely by updating the switch to the latest firmware for access to TRENDnet Hive.This cloud managed switch requires no additional hardware, server, or personal cloud with TRENDnet’s reliable cloud service. With the purchase of each compatible device the first year of TRENDnet Hive for 'Consumers and End Users' is free or you can upgrade to TRENDnet Hive Pro for 'Integrators and Partners' for a nominal annual fee.
The TEG-284WS is suited for a lot of applications. It doesn’t just provide management that can be extended to plug-and-play equipment, it has the power and versatility to enable you to customize your network in the most efficient way possible. Call Westward Sales today, and we’ll help specify the right switch and networking devices to meet your communication needs.
Technology | |
Category | Ethernet Switch |
Total Ports | 28 |
Ethernet Ports | 24 x Gigabit ports |
Fiber Ports | 4 x shared Gigabit ports (RJ-45/SFP) |
Standards | IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.1ab, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az |
Transfer Rate | Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex), Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex), Gigabit Ethernet: 2000 Mbps (full duplex) |
Jumbo Frame Support | 10 KB |
MAC Table Size | 8 K |
Network Management | |
Cloud Protocols | TRENDnet Hive or TRENDnet Hive Pro |
Power | |
Power Consumption | 17.3 W |
Input Connection | 100 - 240V AC, 50/60Hz, internal power supply |
Mechanical | |
Mounting | Rack mountable |
Weight | 2.15 kg (4.73 lbs) |
Dimensions | 440 x 140 x 44mm (17.4 x 5.51 x 1.74 in.) |
Ratings | |
Operating Temperature | -5 - 50°C (23 - 122°F) |
Humidity | 95% non-condensing |
RoHS Compliant | Yes |
Certifications | FCC, CE, UL |
MTBF | 787,004 hours |
Warranty | Lifetime |
Download Name | File Size |
TRENDnet Hive User's Guide | 2.45MB |
TRENDnet Web Smart Switch Series User's Guide | 4.13MB |
TRENDnet TEG-284WS Datasheet | 503.25KB |
