TRENDnet’s TPE-1020SBS Gigabit Web Smart Switch offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of SMB networks. This rack-mountable IPv6-ready managed PoE++ switch comes with an intuitive web-based interface. Advanced managed switch features include LACP to increase bandwidth between switches by grouping ports together, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this managed PoE++ switch a powerful solution for any SMB network. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with an easy-to-use voice VLAN feature.
Installers and integrators can save on equipment costs and reduce installation time with TRENDnet’s Gigabit Web Smart Managed PoE++ Switch by delivering up to 95W of PoE power and data over existing Ethernet cables. With PoE technology, users only need one cable to deliver both data and power. This PoE++ switch is ideal for networking PoE devices, such as high-power wireless access points, PoE lighting, digital signage, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.
The TPE-1020SB gives you complete control over your network. It doesn’t just provide management that can be extended to plug-and-play equipment, it has the power and versatility to enable you to customize your network in the most efficient way possible. At the center of your operation, you want a switch that can handle virtually anything. Talk to us today. We’ll help you make the most of PoE options and other network enhancements to help cut unnecessary equipment and cables while improving overall network performance and capacity.
Technology | |
Category | Ethernet Switch (PoE) |
Total Ports | 10 |
Ethernet Ports | 8 x Gigabit PoE++ ports |
Fiber Ports | 2 x SFP ports |
Standards | IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.1ab, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt |
Transfer Rate | Gigabit Ethernet: 2000Mbps (full duplex), SFP: 2000Mbps (full duplex) |
Jumbo Frame Support | 9 KB |
MAC Table Size | 8 K |
Network Management | |
Cloud Protocols | HTTP/HTTPS (SSL v2/3 TLS version 1.2) Web based GUI |
Power | |
Power Consumption | 5.8W (without PD) / 185.8W (with PD) |
Input Connection | 100 - 240V AC, 50/60Hz, internal power supply |
Mechanical | |
Mounting | Rack mountable |
Weight | 2.38 kg (5.25 lbs) |
Dimensions | 330 x 230 x 44mm (12.80 x 9.06 x 1.74 in.) |
Ratings | |
Operating Temperature | 0° - 40° C (32° - 104° F) |
Humidity | 90% non-condensing |
RoHS Compliant | Yes |
Certifications | FCC, CE, LVD, ETL |
MTBF | 243,000 @ 25° C |
Warranty | Lifetime |
Download Name | File Size |
TRENDnet TPE-1020SB Datasheet | 797.78KB |
TRENDnet TPE-1020SB Quick Installation Guide | 8.76MB |
TRENDnet TPE-1020SB User's Guide | 3.5MB |
