Expand your network’s bandwidth and reduce digital bottlenecks with TRENDnet’s TEG-S5091 9-Port 2.5G unmanaged Switch. This switch comes equipped with eight 2.5GBASE-T RJ-45 ports that provide speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling, and one 10G SFP+ slot for ultra-fast, long-distance fiber networking. It features a durable metal enclosure and can be mounted to the wall for setup flexibility. The fanless design lowers energy consumption and eliminates operating noise. TRENDnet’s reliable 2.5G Ethernet switch with a 10G SFP+ port is a cost-effective solution to increase your network’s throughput.
Count on the TEG-S7102 Ethernet switch for high-performance and dependability. Get more information about this switch and other networking devices by speaking with a network specialist at Westward Sales today.
| Technology | |
| Category | Ethernet Switch |
| Total Ports | 10 |
| Ethernet Ports | 8 x 10G RJ-45 ports |
| Fiber Ports | 2 x 10G SFP+ port |
| Standards | IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.1x |
| Transfer Rate | Gigabit Ethernet: 2000Mbps (full duplex), 2.5G Ethernet: 5Gbps (full duplex), 10 Gigabit Ethernet: 20Gbps (full duplex), 10G SFP+: 20Gbps (full duplex) |
| Jumbo Frame Support | 12KB |
| MAC Table Size | 32K |
| Power | |
| Power Consumption | 40W |
| Input Voltage | 90 - 264V AC, 47/63 Hz |
| Mechanical | |
| Enclosure | Metal |
| Mounting | Rack mountable |
| Weight | 2.54kg (5.6 oz.) |
| Dimensions | 330 x 230 x 44mm (13 x 9 x 1.73 in.) |
| Ratings | |
| Operating Temperature | 0° - 40° C (32 - 104° F) |
| Humidity | Max 90% non-condensing |
| Certifications | FCC, CE, LVD, ETL |
| MTBF | 151,765 hours |
| Warranty | Lifetime |
| Download Name | File Size |
| TRENDnet TEG-S7102 Datasheet | 1002.47KB |
| TRENDnet TEG-S7102 Quick Installation Guide | 7.05MB |
