TRENDnet’s TEG-3524S Gigabit Web Smart Switch offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of today’s SMB networks. This managed switch with SFP+ ports comes with an intuitive web-based interface. Advanced managed switch features include LACP to increase bandwidth between switches by grouping ports together, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this Gigabit managed switch with 10G SFP+ ports a powerful solution for any SMB network. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with an easy-to-use voice VLAN feature.
This managed switch comes equipped with forty-eight RJ-45 ports that provide gigabit speeds over your existing Cat5e or better cabling. The TEG-3524S also offers four dedicated 10G SFP+ ports for high-speed network connections, providing a cost-effective solution in adding 10G link capability to an SMB network. The strategic design of the switch lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable managed switch with SFP+ ports offers a cost-effective solution to increase your network’s throughput.
Count on the TEG-3524S rack-mount Ethernet switch for high-performance and dependability. Get more information about this switch and other networking devices by speaking with a network specialist at Westward Sales today.
Technology | |
Category | Ethernet Switch |
Total Ports | 52 |
Ethernet Ports | 48 x Gigabit ports |
Fiber Ports | 4 x 10G SFP+ ports |
Standards | IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.1ab, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az |
Transfer Rate | Ethernet: 10Mbps (half duplex), 20Mbps (full duplex), Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex), Gigabit Ethernet: 2000Mbps (full duplex), SFP: 2000Mbps (full duplex) SFP+: 20Gbps (full duplex) |
Jumbo Frame Support | 10 KB |
MAC Table Size | 32K |
Power | |
Power Consumption | 20.85 W |
Input Connection | 100 - 240V AC, 50/60 Hz |
Mechanical | |
Mounting | Rack mountable |
Weight | 3.48kg (7.51 lbs) |
Dimensions | 440 x 255 x 44 mm (17.32 x 10.04 x 1.73 in.) |
Ratings | |
Operating Temperature | 0° - 50° C (32° - 122° F) |
Humidity | 90% non-condensing |
RoHS Compliant | Yes |
Certifications | FCC, CE |
MTBF | 175,750 hours |
Warranty | Lifetime |
Download Name | File Size |
TRENDnet Multi-Gig Web Smart Switch Series User's Guide | 4.25MB |
TRENDnet TEG-3524S Datasheet | 1.45MB |
