Manufacturer: TRENDnet
TRENDnet’s TEG-3102WS Multi-Gigabit Web Smart Switch offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of today’s SMB networks. This rack-mountable IPv6-ready managed switch comes with an intuitive web-based interface. Advanced managed switch features include LACP to increase bandwidth between switches by grouping ports together, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this 2.5G managed switch with 10G SFP+ slots a powerful solution for any SMB network. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with an easy-to-use voice VLAN feature.
The TEG-3102WS multi-gigabit managed switch comes equipped with eight 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. The multi-gig managed switch also offers two dedicated 10G SFP+ slots for high-speed network connections, providing a cost-effective solution in adding 10G link capability to an SMB network. The design of the switch lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable TEG-3102WS 2.5G managed switch with 10G SFP+ slots offers a cost-effective solution to increase your network’s throughput.
Any industry that requires 2.5G fiber communication should be trending towards the necessary equipment to support it. Speak with one of our network experts today, and we’ll help you map an affordable transition that puts power where you need it most.
| Technology | |
| Category | Ethernet Switch |
| Total Ports | 10 |
| Ethernet Ports | 8 x 2.5G ports |
| Fiber Ports | 2 x 10G SFP+ ports |
| Standards | IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.1ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3bz |
| Transfer Rate | Gigabit Ethernet: 2000Mbps (full duplex), 2.5G Ethernet: 5000Mbps (full duplex), SFP: 2000Mbps (full duplex), SFP+: 20Gbps (full duplex) |
| Jumbo Frame Support | 10 KB |
| MAC Table Size | 16 K |
| Power | |
| Power Consumption | 152.3 W |
| Input Connection | 100 - 240V AC, 50/60 Hz |
| Mechanical | |
| Mounting | Rack mountable |
| Weight | 664g (1.46 lbs) |
| Dimensions | 240 x 104 x 27mm (9.45 x 4.09 x 1.06 in.) |
| Ratings | |
| Operating Temperature | 0° - 50° C (32° - 122° F) |
| Humidity | 90% non-condensing |
| RoHS Compliant | Yes |
| Certifications | FCC, CE |
| MTBF | 893,944 hours |
| Warranty | Lifetime |
| Download Name | File Size |
| TRENDnet Non-PoE Multi-Gig Web Smart Switch Series QIG | 3.84MB |
| TRENDnet Multi-Gig Web Smart Switch Series User's Guide | 4.25MB |
| TRENDnet TEG-3102WS Datasheet | 1.29MB |
