The TFC-G22SFP 4-Port Gigabit Switch with SFP Ports provides high-bandwidth performance, ease-of-use, and reliability. Boost office network efficiency and eliminate network congestion with gigabit speeds and a total switching capacity of 8Gbps with full-duplex mode. This 4-port switch with SFP ports is ideal to network devices at long distances over fiber connection with its two SFP ports. The wall mountable, fanless design provides installation flexibility.
With a compact and lightweight metal housing design, this gigabit Ethernet switch is well-suited for desktop installations. The fanless design lowers energy consumption and eliminates operating noise. The 4-port switch with SFP ports is compatible with multi-mode and single mode transmissions.
Count on the TFC-G22SFP Ethernet switch for high-performance and dependability. Get more information about this switch and other networking devices by speaking with a network specialist at Westward Sales today.
| Technology | |
| Category | Ethernet Switch |
| Total Ports | 4 |
| Ethernet Ports | 2 Gigabit RJ45 ports |
| Fiber Ports | 2 Gigabit SFP port |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3az |
| Transfer Rate | Ethernet: 10Mbps (half duplex) 20Mbps (full duplex), Fast Ethernet: 100Mbps (half duplex) 200Mbps (full duplex), Gigabit: 2Gbps (full duplex), 100Mbps SFP: 200Mbps (full duplex), Gigabit SFP: 2Gbps (full duplex) Gigabit: 2000Mbps (full duplex) |
| Jumbo Frame Support | 9KB |
| MAC Table Size | 8K |
| Power | |
| Power Consumption | 3.3W |
| Input Voltage | 100 - 240V AC, 50/60 Hz |
| Mechanical | |
| Enclosure | Metal |
| Mounting | Desktop, Wall mountable |
| LED Indicators | Port status |
| Weight | 203.5g (0.45 lbs.) |
| Dimensions | 101 x 75 x 22.6mm (3.97 x 2.95 x 0.89 in.) |
| Ratings | |
| Operating Temperature | 0° - 50° C (32 - 122° F) |
| Humidity | Max 90% non-condensing |
| RoHS Compliant | Yes |
| Certifications | FCC, CE, LVD |
| MTBF | 770,000 hours @ 25° C |
| Warranty | 3 year |
| Download Name | File Size |
| TRENDnet TFC-G22SFP Datasheet | 5.62MB |
| TRENDnet TFC-G22SFP Quick Installation Guide | 4.04MB |
