A mini-tower UPS with line interactive topology, the CyberPower Smart App Sinewave PR1500LCD provides battery backup, power protection (using sine wave output), and surge protection for corporate servers, department servers, storage appliances, network devices, and telecom installations requiring Active PFC power source compatibility. The PR1500LCD uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently.
The extendable LCD Control Panel can be removed and relocated for easy viewing using the attached 4.5 ft. cable. This feature provides easy access to view status or change settings on the UPS when it’s installed in a hard to reach area such as the bottom of a rack, under a desk, in a crowed IT closet, or on the floor.
This model accepts the RMCARD205 network management card for remote management and control via a standard web browser or network management system and includes built-in cloud monitoring. It is pre-installed on the -N model. If necessary, the remote management card may be purchased separately at a later time. See the Product Accessories tab above.
PowerPanel Business Edition Software is a free download and provides IT professionals with tools for monitoring and managing the UPS and backup power.
The PR1500LCD comes with a three-year warranty and a $375,000 Connected Equipment Guarantee.
OL1500LCDN, Smart App Online UPS with pre-installed RMCARD205 network management card
OL1500LCD, Same as above without RMCARD205
CyberPower manufactures professional grade UPSs to satisfy a wide range of battery backup requirements. The PR1500LCD supplies power long enough for equipment to properly shut down when utility power fails. It helps prevent loss of data and minimizes the component stress caused by a hard shutdown. To find out which CyberPower UPS model is best for your project, contact Westward Sales today!
| Technology | |
| Category | Tower UPS |
| Interfaces | |
| Management | Remote management with optional RMCARD205 |
| USB Interface | |
| USB Ports | HID Compliant USB Port |
| Battery | |
| Runtime | 4.7 / 15.1 minutes (full / half load) |
| Battery Type | Sealed Lead-Acid Battery |
| Recharge Time | 3 Hours - Quick Charge Mode, 8 Hours - Eco Mode |
| Transfer Time | 4ms - 8ms |
| Power | |
| Rated Power | 1500 Watts |
| Nominal VA | 1500 VA |
| Output Voltage | 120VAC +/- 5% |
| Input Voltage | 120 VAC |
| Frequency | 50/60Hz +/- 1% |
| Power Factor Correction | 1 |
| Overload | Internal Circuitry Limiting, Circuit Breaker |
| Input Connection | 5-15P 6ft. Cord |
| Output Connection | (8) 5-15R outlets |
| Surge Protection | 1030 joules |
| Mechanical | |
| Enclosure | Mini-tower |
| LED Indicators | Power On, On-Line, Battery Mode, Wiring Fault, Replace Battery |
| Color | Black |
| Material | Metal |
| Weight | 54 lbs. |
| Dimensions | 6.7" W x 8.7" H x 17.0" D |
| Ratings | |
| Operating Temperature | 32 - 104 °F (0 - 40 °C) |
| Humidity | 0% to 90% non-condensing |
| RoHS Compliant | Yes |
| Certifications | UL1778, cUL 107.3, FCC DOC Class A |
| Warranty | Product: 3-year, Connected Equipment: Lifetime |
| Download Name | File Size |
| CyberPower Function Setup Guide 1 | 209.75KB |
| CyberPower PR1000LCD/PR1500LCD User's Manual | 2.91MB |
| CyberPower PR1500LCD Datasheet | 1023.69KB |
| CyberPower PR1500LCDN Datasheet | 530.55KB |
| Image | Model | Product Name | Price | |
 |
RMCARD205 | CyberPower RMCARD205 Network Management Card for UPS Systems | $439.00 |
