Manufacturer: D-Link
The DGS-3130-30TS is a highly versatile Lite Layer 3 stackable switch. Including powerful L2 & L3 features, as well as support for multiple software images, it is highly pliant, capable of accommodating different network deployments.
With network bottlenecks on the rise, the DGS-3130-30TS six 10 Gigabit uplink ports (2 x 10GBASE-T and 4 x 10G SFP+) are an ideal solution. Business can flexibly increase their bandwidth with flexibility to incrementally meet growing bandwidth demands. This switch is also equipped with a USB 2.0 port, allowing users to boot images and upload configuration files directly from, as well as conveniently save syslog files to a USB 2.0 storage device.
The DGS-3130-30TS targets enterprises and metro Ethernet applications, and customers who require a high level of network security and maximum uptime. It supports an external redundant power supply to ensure continued operation. In addition, this switch incorporates essential reliability features to enhance network resilience, including 802.1D Spanning Tree (STP), 802.1w Rapid Spanning Tree (RSTP), 802.1s Multiple Spanning Tree (MSTP), Loopback Detection (LBD), and Broadcast Storm Control. G.8032 Ethernet Ring Protection Switching (ERPS) minimizes recovery time to 50 ms. For load sharing and redundancy backup in a switch cascading/server attachment configuration, the DGS-3130-30TS provides dynamic 802.3ad Link Aggregation Port Trunking.
The DGS-3130 Series allows multiple switches to be combined to form a single physical or virtual stack. This increases redundancy over multiple physical units, simplifies management, and provides a single IP address to manage all members in the stack. Up to 9 switches can be combined using DACs/Fibers to make up to 300 Gigabit Ethernet ports available, allowing switching capacity to be increased with demand.
The DGS-3130TS provides users with the latest security features such as Multi-layer and Packet Content Access Control Lists (ACL), Storm Control, and IP-MAC-Port Binding (IMPB) with DHCP Snooping. The IP-MAC-Port Binding feature allows administrators to bind a source IP address with an associated MAC and define the port number to enhance user access control. With the DHCP Snooping feature, the switch automatically learns IP/MAC pairs by snooping DHCP packets and saving them to the IMPB white list.
Make the most of your network options. Call us today and speak with a genuine networking expert. We can discuss every option to help you build, upgrade, and perfect your network to maximize productivity and minimize cost.
| Technology | |
| Category | Ethernet Switch |
| Total Ports | 30 |
| Ethernet Ports | 24 x 10/100/1000BASE-T, 2 x 10GBASE-T ports |
| Fiber Ports | 4 x 10G SFP+ ports |
| MAC Table Size | 16K |
| Power | |
| Power Consumption | 30.36 W |
| Input Voltage | 100 to 240 VAC, 50 to 60 Hz |
| Mechanical | |
| Mounting | Rack mount |
| Cooling | 1 Smart fan |
| Weight | 3.2 kg (7.05 lbs.) |
| Dimensions | 440 x 250 x 44 mm (17.32 x 9.84 x 1.73 in) |
| Ratings | |
| Operating Temperature | 0 to 50 ˚C (32 to 122 °F) |
| Storage Temperature | -40 to 70 ˚C (-40 to 158 °F) |
| Humidity | 10% to 90% non-condensing |
| Certifications | FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI |
| Safety Standards | CB, cUL, BSMI |
| MTBF | 388,361 hours |
| Download Name | File Size |
| D-Link DGS-3130 Series Hardware Installation Guide | 17.6MB |
| D-Link DGS-3130 Series Datasheet | 669.6KB |
