Manufacturer: D-Link
The DGS-1100-08PV2 switch enables both home and office users to connect Power over Ethernet (PoE) devices such as wireless access points, IP cameras, and IP phones to your network in remote locations without the need for external adapters. Built with small business users in mind, the DGS-1100-08PV2 is compact and operates silently, making it ideal for virtually any room or office. It supports IEEE 802.3af/at Power over Ethernet on all eight copper access ports. Each individual port has capacity to support up to 30W of PoE power, while the switch has an overall budget of 64W eliminating the need for extra power outlets and simplifying your network setup.
With bandwidth control, QoS, VLAN support, and IGMP Snooping this switch optimizes network performance and minimizes congestion. It ensures smooth operation of critical voice and video applications. Featuring an intuitive web-based interface, the DGS-1100-08PV2 switch allows for easy setup and management, making network administration a breeze.
The DGS-1100-08V2 is packed with environmentally and budget friendly technologies. IEEE 802.3az support automatically detects port status, lowering power to those that are unused or have no traffic passing through. The fanless design allows energy-efficient operation, with the added benefit of being silent.
Make the most of your network options. Call us today and speak with a genuine networking expert. We can discuss every option to help you build, upgrade, and perfect your network to maximize productivity and minimize cost.
| Technology | |
| Category | Ethernet Switch (PoE) |
| Total Ports | 8 |
| Ethernet Ports | 8 Gigabit PoE+ ports |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3x, IEEE 802.3az |
| Jumbo Frame Support | 9216 bytes |
| MAC Table Size | 4 K |
| Power | |
| Power Consumption | 83.5 W (PoE on, 3.5 W (PoE off) |
| Input Connection | 100 - 240V AC, 50/60Hz, external power adapter |
| Mechanical | |
| Mounting | Desktop |
| Weight | 0.60 kg (1.32 lbs.) |
| Dimensions | 190 x120 x 38 mm (7.5 x 4.7 x 1.50 in) |
| Ratings | |
| Operating Temperature | 0 - 40°C (32 - 104°F) |
| Humidity | 90% non-condensing |
| RoHS Compliant | Yes |
| Certifications | FCC Class B, CE Class B, VCCI Class B, BSMI |
| Safety Standards | cUL, CE LVD, CB, BSMI |
| MTBF | 786,841 hours |
| Download Name | File Size |
| D-Link DGS-1100V2 Series Datasheet | 448.92KB |
