You can only design a network as good as the equipment comprising it. Optimizing cost versus features is typically the crux of design. In the end, you need components that can dramatically boost efficiency, and in many cases, Power over Ethernet (PoE) is the key. Antaira Technologies knows this, and the LNP-0802 is the switch that provides multi-functionality, customization and raw data speeds that can expand your options and give your network far more capacity with far less hardware and cabling.
Working with PoE reduces complications by eliminating power cables. The 6 PoE+ ports that supply power from the LNP-0802 are rated up to 30 watts each (IEEE-802.3at compliant) making it easy to add the latest PoE devices. The low voltage input range of 12 to 36V accommodates standard industrial cabinets, control panels, machines and solar kits that offer a 24V power source. A voltage booster ups the output to 48 VDC for PoE devices.
As convenient as PoE is, the LNP-0802 is impressive in many other ways. The 6 Fast Ethernet ports give you plenty of communicating power, but the dual 2 km multi-mode or 30 km single-mode fiber ports up the ante. This gives you substantial data management in a form factor that is easy to optimize for distance or bandwidth. Of course, being an Antaira switch, these functions are housed in a robust case that is well protected against extreme temperatures, shocks and vibrations. Extra features like the point break alarm and redundant power input make the switch able to perform with impressive reliability in virtually any setting.
|LNP-0802-M||SC Connector, Multi-Mode, 2 km, Standard operating temperature|
|LNP-0802-M-T||SC Connector, Multi-Mode, 2 km, Extended operating temperature|
|LNP-0802-ST-M||ST Connector, Multi-Mode, 2 km, Standard operating temperature *|
|LNP-0802-ST-M-T||ST Connector, Multi-Mode, 2 km, Extended operating temperature *|
|LNP-0802-S3||SC Connector, Single-Mode, 30 km, Standard operating temperature *|
|LNP-0802-S3-T||SC Connector, Single-Mode, 30 km, Extended operating temperature *|
|LNP-0802-ST-S3||ST Connector, Single-Mode, 30 km, Standard operating temperature *|
|LNP-0802-ST-S3-T||ST Connector, Single-Mode, 30 km, Extended operating temperature *|
* NOTE: The ST and single-mode versions of this product have been discontinued. Multi-mode with dual SC connectors is still available.
From utility monitoring to advanced security, there isn’t an industry that demands more than the LNP-0802-M-24 can meet. With its reasonable price point, it can easily serve as a centerpiece for any part of your network. And its sheer versatility will have you saving bundles on shaved equipment costs. If you really want to make the most of everything we can do for your network needs, get in touch with one of our representatives today. We’ll be happy to help you optimize every piece of your network.
|Ethernet Ports||6 Fast Ethernet (10/100TX) PoE/PoE+, Auto MDI / MDI-X|
|Fiber Ports||2 x 100FX (Multi- Mode 2km, Single-Mode 30km, SC/ST)|
|Wavelength||1310 nm (Multi/Single-Mode)|
|Processing Type||Store and Forward|
|Standards||IEEE 802.3, 802.3u, 802.3x, 802.3at|
|Transfer Rate||14,880pps for Ethernet Port 148,800pps for Fast Ethernet Port|
|MAC Table Size||2K|
|PoE Power Output||Maximum 30 watts per PoE port|
|Power Consumption||145 Watts @ 12 VDC; 200 Watts @ 24 VDC|
|Connection||1 removable 6-pin terminal block|
|Input Voltage||48 to 55 VDC, Redundant | 12 to 36 VDC, Redundant|
|EFT Protection||2,000 VDC for Power Line|
|ESD Protection||6,000 VDC for Ethernet|
|Reverse Polarity Protection||Yes|
|PoE Pin Assignment||Output Pin: 1,2 (V+), 3,6 (V-)|
|Enclosure||Metal, IP30 Protection|
|Dimensions||46 x 142 x 99 mm|
|Mounting||DIN-rail or wall mount|
|Operating Temperature||Standard: -10 to 70°C or Extended: -40 to 75°C|
|Storage Temperature||-40 to 85°C|
|Humidity||5 to 95% non-condensing|
|Certifications||FCC, CE, UL 508, UL Class 1 Division 2, ISA 12.12.01|
