Manufacturer: D-Link
Combining the convenience of Power-over-Ethernet, optimized performance, reliability, and ease of use, the 18-Port DES-1018MPV2 Fast Ethernet PoE Switch with 2 Gigabit up-link ports is the ideal choice for adding PoE devices to a network. It is specifically designed to facilitate easy connections and supply of power to devices such as access points (AP) or IP cameras and phones. But that’s not all. Connect other Ethernet devices such as computers, printers and NASs to unify all your devices under one efficient network ready for any application.
The DES-1018MPV2 features two operating modes: Isolation or Extended mode, each with their own use cases. If both modes are deactivated, ports offer 10/100 Mbps PoE connectivity as standard, with ports 1 to 8 prioritized to optimize the port cache.
Make the most of your network options. Call us today and speak with a genuine networking expert. We can discuss every option to help you build, upgrade, and perfect your network to maximize productivity and minimize cost.
| Technology | |
| Category | Ethernet Switch (PoE) |
| Total Ports | 18 |
| Ethernet Ports | 16x 10 / 100 Mbps PoE ports, 2x 10 / 100 / 1000BASE-T / SFP combo ports |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3x |
| Transfer Rate | Ethernet: 10Mbps (half duplex), 20Mbps (full duplex), Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) |
| MAC Table Size | 16 K |
| Power | |
| Power Consumption | 294.4 watts (PoE on), 9.94 watts (PoE off) |
| Input Connection | Internal AC input: 100 - 240 VAC, 50-60 Hz |
| Mechanical | |
| Mounting | Desktop |
| Dimensions | 11 x 8.3 x 1.7 inches (280 x 230 x 44 mm) |
| Ratings | |
| Operating Temperature | 0° - 40° C (32° - 104° F) |
| Humidity | 5% to 95% non-condensing |
| Certifications | FCC, VCCI, CE |
| Download Name | File Size |
| D-Link DES-1018MPV2 Datasheet | 442.84KB |
