Whether you're setting up a smart home or a robust small business network, the D-Link DGS-1008P has got you covered. NDAA Compliant and backed by a limited-lifetime warranty, this compact and silent-operating switch is perfect for a variety of applications in both smart home and business settings. The fanless design ensures silent operation, making the switch suitable for office spaces, work floors, and areas which are sensitive to noise, such as meeting rooms.
This network switch enables both home and office users to connect Power over Ethernet (PoE) devices such as wireless access points, IP cameras, and IP phones to your network in remote locations without the need for external adapters. Built with home and small business users in mind, the DGS-1008P is compact and operates silently, making it ideal for virtually any room or office. It features 4 10/100/1000BASE-T ports that support the IEEE 802.3af and IEEE 802.3at PoE protocols, supplying between 15 and 30 watts on each PoE port and providing a total power budget of 60 watts. This allows compatible devices to be connected without requiring an additional power supply, saving on cabling and allowing devices to be installed in locations without immediate access to power.
No configuration is required and installation is quick and easy. Auto-MDI/MDI-X support on all ports removes the need for crossover cables when connecting to another switch or hub, and auto-negotiation on each port intelligently adjusts the port speed for optimal compatibility with the connected device. With wire-speed filtering and storeand-forward switching, the DGS-1008P maximizes network performance while minimizing the transmission of bad network packets.
The DGS-1008P features green technology, such as IEEE 802.3az Energy- Efficient Ethernet (EEE), link status detection, and cable length detection. Energy-Efficient Ethernet reduces power consumption of the switch when network utilization is low, reducing the cost of ownership during periods of inactivity. Link status detection automatically powers down ports when there is no link detected, saving power when the connected device has been shut down or disconnected. Cable length detection automatically adjusts the power output of the port based on the length of the cable, reducing the power requirements of the switch to only what is necessary for the installation.
Make the most of your network options. Call us today and speak with a genuine networking expert. We can discuss every option to help you build, upgrade, and perfect your network to maximize productivity and minimize cost.
Technology | |
Category | Ethernet Switch (PoE) |
Total Ports | 8 |
Ethernet Ports | 8 Gigabit ( 10/100/1000BASE-T) |
Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, ANSI/IEEE 802.3, IEEE 802.3x, IEEE 802.3af/at |
Transfer Rate | Ethernet: 10Mbps (half duplex), 20Mbps (full duplex), Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex), Gigabit Ethernet: 2000 Mbps (full-duplex) |
MAC Table Size | 4K |
Power | |
Power Consumption | PoE on: 66.458 W, PoE off: 4.258 W, Standby: 1.037 W |
Input Connection | External 51V/1.2 A power adapter |
Mechanical | |
Mounting | Desktop |
Dimensions | 150 x 98 x 28 mm (5.90 x 3.85 x 1.10 in) |
Ratings | |
Operating Temperature | 0° - 40° C (32° - 104° F) |
Storage Temperature | -20 to 70 ˚C (-4 to 158 ˚F) |
Humidity | 0% to 95% non-condensing |
Certifications | FCC Class B, CE Class B, BSMI, RCM |
Safety Standards | BSMI, LVD |
Warranty | Lifetime |
Download Name | File Size |
D-Link DGS-1008P Datasheet | 731.49KB |
