D-Link DGS-1005P 5-Port Fanless Gigabit PoE+ Unmanaged Desktop Switch, 4 PoE+

D-Link DGS-1005P 5-Port 10/100/100 Unmanaged Desktop PoE+ Switch, PoE Ports 1-4

The D-Link DGS-1005P 5-Port Gigabit Switch with 4 PoE Ports enables you to connect Power over Ethernet (PoE) devices such as wireless access points (APs), IP cameras, and IP phones to the network. Built with home and small business users in mind, the DGS-1005P is compact and operates silently, making it ideal for most rooms and offices.

The DGS-1005P features four 10/100/1000BASE-T ports that support the IEEE 802.3af and IEEE 802.3at PoE protocols, supplying up to 30 W on each PoE port and providing a total power budget of 60 W. You can connect compatible devices to the DGS-1005P without using an additional power supply. This allows you to save on cabling and to install devices in locations without immediate access to power outlets.

No configuration is required and installation is quick and easy. Auto-MDI/MDI-X support on all ports removes the need for crossover cables when connecting to another switch or hub, and auto-negotiation on each port intelligently adjusts the port speed for optimal compatibility with the connected device. With wire-speed filtering and storeand-forward switching, the DGS-1005P maximizes network performance while minimizing the transmission of bad network packets.

The DGS-1005P features green technology, such as IEEE 802.3az Energy- Efficient Ethernet (EEE), link status detection, and cable length detection. Energy-Efficient Ethernet reduces power consumption of the switch when network utilization is low, reducing the cost of ownership during periods of inactivity. Link status detection automatically powers down ports when there is no link detected, saving power when the connected device has been shut down or disconnected. Cable length detection automatically adjusts the power output of the port based on the length of the cable, reducing the power requirements of the switch.

Key Features

• 5x Gigabit Ethernet ports (4x PoE+ ports)
• 60W power budget
• 10 Gbps switching fabric capacity
• Plug & play simplicity for easy installation
• Ultra-quiet compact design for home and office use
• Sturdy metal housing
• NDAA Compliant
• Lifetime Warranty

In the Box

1. DGS-1005P
2. Power Adapter (53.5 V, 1.2 A)
3. Power Cable
4. Mounting Kit
5. 4 Rubber Feet
6. Quick Install Guide
