The DMS-108 8-Port Multi-Gigabit unmanaged Switch is ideally suited for Small Office Home Office (SOHO) environments. With a durable design, silent operation, and plug-and-play functionality, the DMS-108 switch can be easily set up and be placed in almost any location where network connectivity is required. Support for IEEE 802.3az Energy-Efficient Ethernet (EEE), 802.1p Quality of Service (QoS), and multi-Gigabit Ethernet connection speeds provide advanced features in a compact package.
Auto-negotiation intelligently senses the link speeds of your devices and adjusts between 3-speeds (100Mb/1G/2.5G) for compatibility and optimal performance. The 802.1p QoS feature allows traffic to be classified in 8 priority levels, depending on their importance. Flow Control helps minimize dropped packets for a more reliable connection for all of your connected devices. IGMP Snooping optimizes multicast data streams for bandwidth-intensive applications.
The DMS-108 has a sturdy and compact metal housing to ensure the product can withstand wider operating temperatures by helping to dissipate heat and reduce stress on internal components. IEEE 802.3az Energy-Efficient Ethernet (EEE) reduces power consumption when ports are not in use, conserving energy and lowering costs.
The DMS-108 is easy to setup with no software installation or configuration needed. It is backward compatible with Cat5 and Cat6 cables and features per port LED indicators for easy link status display.
Make the most of your network options. Call us today and speak with a genuine networking expert. We can discuss every option to help you build, upgrade, and perfect your network to maximize productivity and minimize cost.
Technology | |
Category | Ethernet Switch |
Total Ports | 8 |
Ethernet Ports | 8x 10/100Mbps/1G/2.5G |
Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3x, IEEE 802.1p, IEEE 802.3az |
MAC Table Size | 4K |
Power | |
Power Consumption | 8.586 W |
Input Connection | External 12 V / 1 A |
Mechanical | |
Mounting | Desktop |
LED Indicators | Power, Link/Activity per port |
Weight | 343 g |
Dimensions | 145 x 82 x 28 mm |
Ratings | |
Operating Temperature | 0° - 40° C (32° - 104° F) |
Storage Temperature | -10 to 70 ˚C (14 to 158 ˚F) |
Humidity | 10% to 90% non-condensing |
Certifications | CE Class B, RCM Class B, FCC Class B, VCCI Class B, IC Class B, BSMI Class B |
Safety Standards | BSMI, LVD |
MTBF | 724,033.96 hours |
Warranty | Lifetime |
Download Name | File Size |
D-Link DMS-108 Datasheet | 458KB |
D-Link DMS-108 Quick Installation Guide | 3.49MB |
