Axiomtek NA860 2U Network Appliance, Dual LGA3647 Socket for Intel Xeon CPUs

Axiomtek NA860 Network Appliance for Intel Xeon Scalable Processors, Up to 66 Gigabit LAN Ports

Axiomtek's NA860 network appliance is a powerful and flexible 2U rackmount network appliance platform powered by the high-end dual LGA3647 socket 2nd Generation Intel Xeon Scalable processors along with the Intel C621 chipset. The NA860 scales up to twenty-eight cores for higher computing performance. The robust 2U network appliance platform improves performance and brings faster and more secure networks in a wide range of applications such as digital security and surveillance, SDN, NGFW, IDS, IPS, UTM, etc.

Powered by 2nd Generation Intel Xeon Scalable processors, the dual-processor-based 2U rackmount network computing system comes with variety of advantages including high performance, greater memory bandwidth, and advanced capability to enable AI for IoT. It supports a maximum of sixty-six Gigabit LAN ports through an integration of up to eight expandable NIC modules, allowing it to manage numerous connected computers. These NIC modules feature support for 1G/10G/25G/40G Ethernet speeds, fiber, copper and bypass. Moreover, the NA860 is equipped with twelve DDR4-2400 R-DIMM slots supporting up to 384GB of non-buffer non-ECC/ECC memory for higher memory speeds. The server-grade network appliance platform also has two 2.5-inch hot swappable SATA HDD trays at the front of the system and one mSATA slot for storage expansions. Two PCIe x8 expansion slots are available for an add-in riser card (AX96709 optional).

The Axiomtek’s NA860 has been designed to meet the growing needs of increased data traffic across many high-speed connections in industrial markets. With the latest 2nd Generation Intel Xeon Scalable processor, the 2U rackmount network appliance boosts performance and offers high bandwidth and crypto throughput for diverse applications from machine control to edge data processing.

To fulfill a variety of vertical application needs, the NA860 has rich I/O interfaces including one RJ-type RS-232 port, two USB 3.0 ports, two RJ-45 GbE LAN ports with Intel Ethernet Controller i210 and one VGA port. The incredible Intel Xeon processor-based network security platform features Intelligent Platform Management Interface (IPMI) to allow users to remotely manage and monitor servers. It also supports Trusted Platform Module 1.2 to provide data encryption for secure hardware-based data protection.

Key Features

• Dual LGA3647 socket 2nd Generation Intel Xeon Scalable processors and Intel C621 chipset
• Twelve DDR4-2400 R-DIMM unbuffered non-ECC/ECC memory, max. up to 384GB
• Maximum of sixty-six 10/100/1000 Mbps Ethernet ports
• Eight expandable LAN modules supporting 1GbE/10GbE/25GbE/40GbE/Fiber/Copper/Bypass
• 800W 2U redundant power supply
• Supports IPMI/TPM (onboard) for option
• High computing power for digital security & surveillance, SDN, NGFW, IDS, IPS and UTM applications

Accessories (Call for pricing)

1. DB9F-RJ45 1.8 M Console cable for Cisco
2. AX96709 riser card 2xPCIe8

In the Box

1. NA860
2. SATA cable
3. Power Cord
