Patton CopperLink CL2380R Industrial Long-Range Ethernet Extender to 4 Miles

Patton CopperLink CL2380R Long-Range Hybrid Copper-Fiber Ethernet Extender, up to 4 Miles

The Patton CL2380R Series is an Ethernet Extender, Switch and Router that delivers high speed connectivity for Ethernet-over-Copper, Fiber or both. Offering 8 Ethernet Ports including 6 LAN and 2 SFP WAN ports together with Northbound and Southbound facing Long-Range Extension ports, the CL2380R is ideal for integrating local copper-based industrial ethernet to regional fiber backbones. The unit offers six (6) RJ-45 local Ethernet LAN Ports, two (2) gigabit Ethernet WAN SFPs ports, two (local/remote, north/south) long-range copper extension ports, plus digital input, and digital output ports for controlling industrial devices, sensors, alarms, or controls.

As a combination Ethernet Extender, Ethernet Switch and Ethernet Router, the CL2380R offers Layer 3 capabilities supporting IP protocols required for routing, management and security required for critical industrial infrastructure.

A special relay switch between the two Copper Extension ports (local/remote, north/south) enables the unit to be bypassed (directly connects the copper lines) if the unit is shut down.

A Digital Output interface is used as an Alarm Relay indicating the power status of the unit. When the unit is powered OFF, this relay is closed (Alarm mode) and when the unit power is ON, this relay is open. Digital Inputs support dry-contact mode, where the absence of voltage corresponds to zero (o) and a voltage of 5V to 15V DC corresponds to 1. The Digital Input can be used for a variety of purposes subject to future or customized firmware releases.

Security is enhanced with a laundry list of cyber features including firewall filtering, IPSec tunneling (with IKEv2 and Hub-and-Spoke functions), Simple Certificate Enrollment Protocol (SCEP), X.509 authentication and PKI enrolment. It embeds a Secure-Element for enhanced authentication certificate control, strong encryption of stored information and Secure-Boot to ensure total security of both data and software.

Key Features

• Long Range Ethernet extender for distances to 4 miles
• 6 Fast Ethernet (10/100TX) ports with Auto-MDIX and full or half-duplex operation
• Achieves up to 15Mbps over 1 twisted pair
• Supports point-to-point, multi-point, daisy-chain, and ring topologies
• Includes network management and firewall
• Via local USB port (Host/Device), via SSH, HTTP, HTTPS, SNMP, FTP and intuitive Web User Interface
• -20 to +60°C operating temperature
• DIN Rail mounting kit included

Configurations

CL2386R/DC, Six RJ-45 local Ethernet LAN Ports, Two gigabit Ethernet WAN SFPs, Two 1-Pair (2-Wire) line interfaces, 9-55 VDC Power
CL2386R/SP/DC, Same as above with Primary Surge Protection

CL2386R/EUI, Six RJ-45 local Ethernet LAN Ports, Two gigabit Ethernet WAN SFPs, Two 1-Pair (2-Wire) line interfaces, 110-230 External AC Power
CL2386R/SP/EUI, Same as above with Primary Surge Protection
