TRENDnet TPE-E100 Gigabit PoE+ Extender, 1G Input Port & 1G Output Port

New TRENDnet TPE-E100 Power over Ethernet extender, daisy chain 3 units, wall mountable
Model: TPE-E100
Availability: Normally in Stock
Standard Shipping & Handling
Qty: Add to Cart

TRENDnet TPE-E100 Gigabit PoE+ Extender, Daisy-Chainable for 3 Units, Wall Mount

TRENDnet’s TPE-E100 Gigabit PoE+ extender takes a single PoE+ connection and extends it an additional 100m (328 ft.) for remote PoE/PoE+ device installation. The PoE Extender auto-detects a PoE (15.4W) or PoE+ (30W) connection and extends it for a total distance of up to 200m (656 ft.) from the PoE+ power source equipment. The TPE-E100 features a convenient wall mountable design for installation flexibility. Daisy-chain up to 3 units for a total PoE+ network extension of 400m (1312 ft.).

Key Features

  • Easy installation
  • Extends 100m for a total distance of up to 200m (656 ft.)
  • Daisy chain up to 3 units for a total PoE network extension of up to 400m (1312 ft.)
  • Supports PoE (15.4W) and PoE+ (30W)
  • One gigabit PoE+ input port and One gigabit PoE+ output port
  • Wall mountable
  • LED Indicators
  • Durable metal housing
  • NDAA compliant

In the Box

  1. TPE-E100
  2. Quick Installation Guide
Technology
CategoryEthernet Extender
Total Ports2
Ethernet Ports1 x Gigabit PoE+ input, 1 x Gigabit PoE+ output
Transfer RateEthernet: 10Mbps (half duplex), 20Mbps (full duplex), Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex), Gigabit: 2000Mbps (full duplex)
Jumbo Frame Support9KB
MAC Table Size2K
Power
PoE Power Output30 Watts
Power Consumption0.9W
Mechanical
MountingWall mountable
Weight198g (7 oz.)
Dimensions86 x 79 x 25mm (3.4 x 3.1 x 1 in.)
Ratings
Operating Temperature0° - 40° C (32° - 104° F)
Humidity90% non-condensing
CertificationsCE, FCC
Warranty3 year
Tags: TPE-E100
