TRENDnet TPE-E110 Gigabit PoE+ Extender, 1G Input Port & 1G Output Port

New TRENDnet TPE-E110 Power over Ethernet extender/amplifier, daisy chain 5 units, wall mountable
Model: TPE-E110
Availability: Normally in Stock
Standard Shipping & Handling
Qty: Add to Cart

TRENDnet TPE-E110 Gigabit PoE+ Extender/Amplifier, Daisy-Chainable for 5 Units, Wall Mount

TRENDnet’s TPE-E110 Gigabit PoE+ Extender/Amplifier takes a single PoE+ connection and extends it an additional 100m (328 ft.) for remote PoE/PoE+ device installation. The TPE-E110 auto-detects a PoE (15.4W) or PoE+ (30W) connection and extends it for a total distance of up to 200m (656 ft.) from the power sourcing equipment. Daisy chain up to 5 units for a total PoE+ network extension of 600m (1,968 ft.). The extended range and convenient wall mounting design allows for greater installation flexibility.

Key Features

  • Easy installation
  • Extends 100m for a total distance of up to 200m
  • Daisy chain up to 5 units for a total PoE+ network extension of 600m
  • PoE/PoE+ powered
  • Wall mountable
  • Durable metal housing
  • NDAA compliant
  • 3-Year warranty

In the Box

  1. TPE-E110
  2. Quick Installation Guide
Technology
CategoryEthernet Extender
Total Ports2
Ethernet Ports1 x Gigabit PoE+ input, 1 x Gigabit PoE+ output
Transfer RateEthernet: 10Mbps (half duplex), 20Mbps (full duplex), Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex), Gigabit: 2000Mbps (full duplex)
Jumbo Frame Support9KB
MAC Table Size2K
Power
PoE Power Output30 Watts
Power Consumption1.6W
Mechanical
MountingWall mountable
Weight242g (8.5 oz.)
Dimensions121 x 75 x 26mm (4.77 x 2.95 x 1 in.)
Ratings
Operating Temperature0° - 40° C (32° - 104° F)
Humidity90% non-condensing
CertificationsCE, FCC
Warranty3 year
