Manufacturer: Axiomtek
The IPC970 is an embedded system that supports the LGA1200 socket for Intel Xeon and 10th generation Corei7/i5/i3 processors with the Intel® W480E chipset. It supports Windows 10 and Linux, with a rugged design that makes it suitable for the most endurable operation.
The powerful edge computing system supports NVIDIA® GeForce RTX™ 3090 graphics card with 10,496 CUDA cores and a whopping 24GB of GDDR6X memory for powerful GPU computing capability. The ruggedized IPC970 provides flexible expansion options with one I/O module slot and three PCIe slots plus one blank expansion slot. In addition, it has a full-size PCIe Mini Card slot for Wi-Fi/Bluetooth/LTE modules, one M.2 Key B 3042/3050 socket for 5G wireless connections, and one M.2 Key E 2230 socket for Wi-Fi/Bluetooth modules. Its front-facing I/O design makes it easy to access and deploy. To ensure stable and reliable operation in harsh industrial environments, the IPC970 has a wide operating temperature range of -10°C to +70°C and a power input of 24V DC (uMin=19V/uMax=30V) with power-on delay function, over-voltage protection, over current protection, and reverse voltage protection.
The IPC970 features four DDR4-2933 ECC/non-ECC U-DIMM slots with up to 128 GB of system memory. It offers two swappable 2.5” SSDs/HDDs, an optional internal 2.5” SSD/HDD with the support of Intel® RAID 0,1 and one M.2 Key M 2280 socket for additional storage. The industrial system supports rich I/O options including two GbE LAN ports, eight USB 3.2 ports, one internal USB 2.0 port, one VGA, one HDMI, one 4-pin terminal block, one audio (line-out), and one AT/ATX selectable switch. It is also wall-mountable and offers Trusted Platform Module 2.0 (TPM 2.0) for enhanced security.
Axiomtek’s powerful IPC970 has four choices of I/O modules - AX93511, AX93512, AX93516, and AX93519 - to meet the requirements of various applications. Additionally, the highly versatile industrial system has three high-speed PCIe slots for vision, motion, data acquisition, and I/O cards. It also has a built-in power board for supplying an additional 400W for high power consumption PCI/PCIe add-in cards.
AX93511 - 4x RS-232/422/485 module (default RS-232)
AX93512 - 2x RS-232/422/485 with isolated 1.5kVDC & 8-in/8-out with isolated 1.5kVDC DIO module
AX93516 - 4x RS-232/422/485 with isolated 2kVDC module
AX93519 - 1x 10/100/1000 Mbps (Intel® I211-AT) Ethernet, 2x RS-232/422/485 & 2x USB 3.0 (USB 2.0 signal) module
External fan module kit
Wall mount bracket kit
Internal SSD/HDD bracket kit
Memory holder bracket
2.5" SATA HDD/SSD
DDR4-2933 MT/s ECC or non ECC U-DIMM
| Technology | |
| Category | Industrial Computer |
| Ethernet Ports | 1x 2.5 Gigabit LAN (Intel i225-LM), 1x Gigabit LAN (i219-LM) |
| Computing | |
| System Type | Embedded Computers |
| CPU | Intel Xeon | Intel Core |
| Chipset | Intel W480E |
| Maximum System Memory | 128 GB |
| System Memory Configuration | 4 x DDR4-2933 MT/s ECC or non-ECC U-DIMM socket, up to 128GB |
| Drive Storage | 2x SSD/HDD drive bay, 1x SSD/HDD drive bay (optional), 1x M.2 Key M 2280 socket (PCIe Gen3 x4) for NVMe SSD |
| Operating Systems | Windows 10, Linux |
| Interfaces | |
| USB | 6 x USB 3.2 Gen.2 (10G), 2 x USB 3.2 Gen.1, 1 x USB 2.0 (internal, 180D type A for license key) |
| Video Ports | 1 x VGA, 1 x HDMI |
| Audio | 1x Line-out |
| Power | |
| Power Consumption | 80 W |
| Input Voltage | 24 VDC |
| Mechanical | |
| Enclosure | Aluminum extrusion and heavy-duty steel |
| Dimensions | 190 x 192 x 360 mm (7.48" x 7.55" x 14.17") |
| Weight | 9.8 kg |
| LED Indicators | 1 x HDD/SSD access LED 3 x User's LED |
| Ratings | |
| Operating Temperature | -10°C to +60°C |
| Humidity | 10 to 90% non-condensing |
| Certifications | CE |
| Download Name | File Size |
| Axiomtek IPC970 Datasheet | 447.94KB |
| Axiomtek IPC970 User's Manual | 3.28MB |
