Manufacturer: Antaira Technologies
A PoE injector is a brilliant low-cost solution for the case where only one side of a device is supporting PoE function. Antaira Technologies’ INJ-C201G-bt-100-T (-24-T) solves the problem simply by deploying data and power from a non-PoE switch and power input to the PD device. The INJ-C201G-bt-100-T (-24-T) is your best choice to deal with the lack of PoE function.
The INJ-C201G-bt-100-T supports power input from 48 VDC to 55 VDC and the INJ-C201G-bt-100-24-T supports low voltage 9 VDC to 55 VDC with power booster technology. This ensures full 90W PoE output, in compliance with IEEE 802.3bt standard, for better usage in the automation industry. Moreover, for some special applications which eager for more PoE power from the PSE device, these models also supports Enhanced PoE mode to offer up to 100W to the powered device. Made for industrial or outdoor settings, the DIN-rail mount case and hardened electronics feature a broad operating temperature range to endure extreme heat and cold. With compliance to electrical and safety standards and a 5-year warranty, you can rest easy knowing this injector will reliably operate in the most demanding applications. Compare this injector to the 90W version, INJ-C201G-bt-T.
INJ-C201G-bt-100-T, Industrial Gigabit Enhanced PoE++ Injector with 48-55 VDC Power Input
NJ-C201G-bt-100-24-T, Same as above with 9-55 VDC Power Input
Bringing high-powered Power over Ethernet equipment online is only the start. Every industrial network has challenges, and our sales staff has the experience to help with yours. Contact us today to see how we can boost your performance and reduce costs.
| Technology | |
| Category | PoE Injector & Splitter |
| Total Ports | 2 |
| Ethernet Ports | 2 Gigabit (10/100/1000TX) |
| Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3af/at/bt |
| Functionality | PoE Injector |
| Transfer Rate | 14,880pps for Ethernet Port, 148,800pps for Fast Ethernet Port, 1,148,000pps for Gigabit Port |
| Power | |
| PoE Power Output | 100 Watts |
| Power Consumption | 1.6 W (standby without PoE load) |
| Connection | 4-Contact Terminal Block |
| Input Voltage | 48 to 55 VDC |
| Reverse Polarity Protection | Yes |
| Overload Protection | Yes |
| Mechanical | |
| Enclosure | Metal, IP30 Protection |
| Mounting | DIN-Rail & Wall Mounting |
| Shock / Vibration | IEC 60068-2-6, IEC 60068-2-27 |
| LED Indicators | Power and PoE |
| Weight | 0.80 lbs |
| Dimensions | 30 x 95 x 75 mm |
| Ratings | |
| Operating Temperature | -40 to 75°C |
| Storage Temperature | -40 to 100°C |
| Humidity | 5 to 95% non-condensing |
| RoHS Compliant | Yes |
| Certifications | FCC, CE, UL, cUL |
| Warranty | 5 Years |
| Download Name | File Size |
| Antaira INJ-C201G-bt-T Datasheet | 9.59MB |
| Antaira INJ-C201G-bt-100-T Datasheet | 15.31MB |
| Antaira INJ-C201G-bt-100-T Hardware Manual | 1.63MB |
