Peplink ANT-MAX-DUO 11:1 Outdoor Dual Router Enclosure with Cellular, WiFi, & GPS

Peplink ANT-MAX-DUO 11:1 High-Gain Integrated Antenna and Router Enclosure, 5G LTE, WiFi, GPS

The ANT-MAX-DUO is a powerful outdoor solution that combines high-performance antennas with a rugged enclosure, designed to extend your router’s capabilities and enable outdoor use. It delivers high gain, zero cable loss, easy installation, and IP67-rated outdoor design - while adding something more: greater flexibility. With the cellular antenna array of eight high-gain elements, two Wi-Fi, and GPS antenna elements the MAX Duo lets you power a dual-modem 5G router like the BR2 Pro, or even two single 5G routers, all within one enclosure. It’s a space-efficient, time-saving, cost-effective, and performance-maximizing solution for maritime, mobile, enterprise, and remote deployments.

It mounts easily on mobile equipment and vehicles - trucks, vans, boats. The Antenna MAX Duo is neither a router nor a traditional antenna like the Mobility or Maritime Antenna Series. It is designed to house selected Peplink routers and enhance their connectivity using the Antenna MAX Duo's built-in antenna elements. The ANT-MAX-DUO is compatible with the BR2 Pro, the BR1 Pro 5G, and the BR1 Mini 5G in various setups. The integrated design removes the need for external RF cabling, reducing signal loss and setup complexity. Using the Splitter MAX, both connectivity and power are managed through a single PoE cable.

It operates safely between -40 and 80°C, making it tougher than most outdoor temperatures worldwide. Built to endure the elements, the Antenna MAX Duo is engineered for harsh environments with a UV-stable, waterproof IP67-rated enclosure and flame-retardant, UV-resistant plastics. Compliant with MIL-STD 810F salt spray standards, it’s ready to perform reliably on land, at sea, and on the move.

Key Features of the ANT-MAX-DUO

• Omnidirectional 8x8 MIMO 5G LTE, MIMO WiFi, and GPS antenna
• 8x8 MIMO 5G LTE with 617 - 6000 MHz frequency range
• MIMO WiFi with 2.4 - 2.5 and 5.0 - 6.0 GHz frequency range
• GPS with 1575 - 1602 MHz frequency range
• UV-resistant plastic enclosure resists moisture, water intrusion, salt spray and corrosion
• Up to 8.1 dBi gain
• Compatible with selected Peplink routers
• Surface or pole mount
• 10 W maximum power rating
• -40º to 80º C Operating Temperature
• Right angled SMA (M) and RP-SMA (M) connectors

In the Box

1. Antenna MAX Duo
2. L-Mount Set
3. Router fixation screws
4. 5 pcs Rubber Support TNF-19
5. 3 pcs Rubber Support TF-039
6. 3 pcs RJ45 glands
7. 2 pcs RJ45 caps
8. 1 pcs Double sided 3M adhesive pad
9. 1 pcs Ethernet cable (9.84" / 250mm)
10. 1 pcs Ethernet cable (14.96" / 380mm)
