Falcon SG1KRM (-1SC,-2SC) 1 kVA UPS, UL Rated, 5-Year Batteries, Standard Temp

Falcon SG1KRM Industrial 1 kVA UPS, UL Rated, 5-Year Batteries
Model: SG1KRM
Availability: 1 Week
Standard Shipping & Handling

Choose Options


Voltage Input:

UPS Additions:







Qty: Add to Cart

Falcon SG1KRM On-Line 1 kVA UPS, 120 or 230 VAC Input, UL 1778 Rated, 5-Year Batteries

The SG1KRM UPS from Falcon Electric brings industrial reliability and a high-level of power protection at a cost-effective price. It offers true on-line 1000 VA and 900 watts in a rugged 2U rackmount package. The SG1KRM is an economical version of the SSG1.5KRM ultra-industrial UPS. Even though it has a standard operating temperature and integrated 5-year rated battery, it doesn’t sacrifice backup power quality.

The SG1KRM is suitable for any application that requires dependable stand-in power. The double-conversion design (AC to DC / DC to AC) regenerates a perfect sinewave output regardless of input. This architecture isolates the load from power input irregularities. Should the primary power fail, batteries feed the load with no interruption (zero transfer time). The system also includes power factor correction, frequency regulation, surge suppression, and filtering. Select from the 120 VAC input model (-1SC) or the 240 VAC (-2SC) one. Monitoring and configuration are available through the easy-to-use LCD panel or a USB, RS-232, or optional Ethernet. It supports both 50 and 60 Hz AC frequencies which may be switched by the user.

Key Features

  • Reliable, long-life on-line industrial UPS
  • 1 kVA / 900 watts output
  • 3 minutes full load / 9 minutes half-load battery runtime
  • Choose 120 or 240 VAC input
  • User-programmable AC voltage output
  • Programmable 50 or 60 Hz frequency converter
  • Includes internal 5-year rated, maintenance-free, sealed VRLA batteries, 12 VDC, 9 Ah
  • Monitoring via USB, RS-232, and optional SNMP/HTTP board
  • User-friendly LCD featuring status and load levels
  • UL 1778, FCC Class A, CE agency approvals
  • 2U, 19” rack mount, 16” depth
  • * Optional battery bank, SGCB-1S9-24V-1NC, 24 Vdc, 12V, 9Ah (-1SC) or SGCB-1S9-36V-1NC, 36 Vdc, 12V, 9Ah (-2SC)

Configurations

SG1KRM-1SC, 1 kVA rackmount UPS with 120 (90 to 150) VAC input
SG1KRM-2SC, 1 kVA rackmount UPS with 240 (180 to 300) VAC input

Falcon Electric is a recognized leader in industrial UPS systems. Their SG1KRM satisfies industrial applications needing reliable backup power at an affordable price. You’ll find this UPS to be ideal for water and wastewater treatment plants, production facilities, control panels, and petroleum operations. Contact Westward Sales to discuss the configuration options that will meet your power needs.



Falcon UPS Awards

Technology
TypeRackmount
Power
Rated Power900 Watts
Nominal VA1000 VA
Output VoltageUser programmable: 100, 110, 115, or 120 VAC (-1SC model) or 208, 220, 230, or 240 VAC (-2SC model)
Input VoltageSelect 120 (90 to 150) VAC or 240 (180 to 300) VAC
Frequency50 / 60 Hz (auto tracking)
Power Factor Correction0.99 at full linear load
Overload< 105% continuous; > 105-120% for 30 seconds and transfer to bypass; > 150% immediate transfer to bypass
Input Connection5-15P or Schuko plug, 6’ Cord
Output Connection(6) 5-15R or (4) IEC320 C13 outlets
Surge ProtectionEN-61000-4-5
Efficiency>90%
Battery
Runtime3 / 9 minutes (full / half load)
DC Bus Voltage (nominal)24 VDC (-1SC model) and 36 VDC (-2SC model)
Battery Type5-Year Rated, Maintenance-Free, Sealed VRLA Batteries, 12 VDC, 9 AH
Recharge Time4 hours to 90% capacity
Transfer Time< 4ms UPS to Bypass / Reverse, Auto Transfer to UPS after Overload
Mechanical
Dimensions2U 19" Rack Mount, 16" Depth
Weight29 lbs.
LED IndicatorsNormal, Battery, Bypass, Self-Test, Battery Fault, Site Wiring Fault, UPS Fault, Overload, and Load/Battery Level
Ratings
Operating Temperature0 to 40ºC (32 to 104ºF), the battery service life will be reduced above 25ºC
Storage Temperature-10 to 50ºC (14 to 122ºF), batteries stored above 50ºC will require monthly recharging and have a reduced service life.
Humidity10% to 95% non-condensing
CertificationsUL 1778, FCC Class A, and CE
