ARBOR AEC-2000 NVIDIA Jetson Orin Edge Nano AI Embedded Computer

New ARBOR AEC-2000 NVIDIA Jetson Orin Nano AI Embedded Computer, 3 USB, HDMI video, 4 or 8 GB memory
Model: AEC-2000
Availability: Contact Westward Sales
Standard Shipping & Handling
Qty:

ARBOR AEC-2000 NVIDIA Jetson Orin NanoAI Embedded Computer with USB 3.2 and HDMI Port

ARBOR's edge AI computing solutions deliver unparalleled performance in harsh environments and offer wide-temperature operation to prevent thermal throttling. Highlighted here is the AEC-2000 AI Embedded Computer supporting NVIDIA Jetson Orin Nano. It features 1x GbE port, 2x USB 3.2 type A & 1x USB 2.0 type C ports, and 1x HDMI Video port. It is available with 4 or 8 GB memory.

Tailored for lower-power AI workloads, the AEC-2000 combines edge inferencing capabilities with a rugged design, making it ideal for embedded AI tasks in transportation, logistics, and public safety environments.

Seamlessly integrate advanced AI algorithms directly into your industrial processes, enabling real-time analytics, predictive maintenance, and autonomous computing at the edge. With robust computing power and a wide range of application support, ARBOR's edge AI platforms redefine productivity and efficiency in your operations.

Key Features

  • Supports NVIDIA Jetson Orin Nano
  • Supports 1x GbE LAN
  • 2 x USB 3.2
  • 1 x HMDI 2.0 port
  • DC 9-24V wide range power input
  • Operating Temperature -25°C - +50°C

* Contact Westward Sales today to customize your AEC-2000 AI Embedded Computer.

Technology
CategoryIndustrial Computer
Computing
System TypeAI GPU Computers
CPUARM Cortex
Maximum System Memory8 GB
System Memory Configuration4GB/ 8GB LPDDR5 DRAM
Expansion Slots1 x M.2 M-Key 2280 Socket (for NVMe SSD), 1 x M.2 E-Key 2230 Socket (for WiFi module), 1 x 2x10-pin headers for 2xI2C, 1 x UART, 9-bit DIO
Operating SystemsLinux / NVIDIA JetPack 6.2
Interfaces
LAN Ports1 Gigabit Ethernet
USB1 x USB 2.0, 2 x USB 3.2
Video PortsHDMI 2.0
AudioNo
Power
Input Voltage9 to 24V DC
Mechanical
MountingDesk-Mount, Wall-Mount
Shock / VibrationMIL-STD-810H, MIL-STD-810G
Antenna ConnectionAntenna hole for WiFi
Weight2 kg
Dimensions130 x 8 x 49 mm
Ratings
Operating Temperature-25°C to 50°C (-13°F to 122°F)
Storage Temperature-40 to 85°C (-40 - 185°F)
Humidity95%
EMCCE,FCC
Download NameFile Size
ARBOR AEC-2000 Series Datasheet1.9MB
