Antaira LNP-201AG-T Industrial Gigabit PoE Injector, IEEE 802.3at, DIN-rail Mount

Antaira LNP-201AG-T  IEEE 802.3at Gigabit PoE Injector
Model: LNP-201AG-T
Availability: 86 In Stock
FREE SHIPPING !
Qty: Add to Cart

Add PoE Devices to Your Network with Antaira's Industrial-Grade LNP-201AG-T Injector

Adding PoE equipment to your network is simple using the LNP-201AG-T injector. This helpful device connects and powers PoE/PoE+ devices compliant to the IEEE802.3af/at standard. The LNP-201AG-T accepts a Fast or Gigabit Ethernet (10/100/1000T) connection and outputs data and power through a second Ethernet cable. In this manner, an injector eliminates the need to run a separate power cable to cameras, wireless access points, fire alarms, and other PoE enabled electronics. Network traffic passes normally through the injector without interruption.

With industrial-grade quality, the LNP-201AG-T offers a broad operating temperature range to endure extreme hot and cold conditions. It complies with FCC, CE, IEC, and UL electrical and safety standards. It features a wide input range for power and includes electrical isolation and protection from voltage surges and shorts. The LNP-201AG-T is reliably built for applications like security and surveillance, automation control cabinets, transportation, and power utilities.

Key Features

  • Gigabit Ethernet (10/100/1000T) input and output
  • Meets the IEEE802.3af/at specification
  • Outputs up to 30 watts to PoE+ equipment
  • 24 to 48 VDC power input, 6-pin terminal block
  • Isolation and overload protection
  • IP30 metal enclosure
  • Wide operating temperature of -40° to 75°C
  • DIN and wall mounting brackets included
  • 5-year warranty
Technology
CategoryPoE Injector & Splitter
Total Ports2
Ethernet Ports1 Gigabit (10/100/1000TX) data input; 1 Gigabit (10/100/1000TX) (PoE output)
StandardsIEEE 802.3, 802.3u, 802.3ab, 802.3af/at
FunctionalityPoE Injector
Power
PoE Power Output30 Watts (PoE+)
Power Consumption33.36 W @ 24 VDC
Connection1 removable 6-pin terminal block
Input Voltage24 to 48 VDC, Redundant
Overload ProtectionYes
Mechanical
EnclosureMetal, IP30 Protection
Dimensions30 x 140 x 95 mm
Weight1 lb.
MountingDIN-rail or wall mount
Ratings
Operating Temperature -40 to 75°C
Storage Temperature-40 to 85°C
Humidity5 to 95% non-condensing
RoHS CompliantYes
Certifications FCC Class A, CE EN61000-4-2 (ESD), CE EN61000-4-3 (RS), CE EN-61000-4-4 (EFT), CE EN61000-4-5 (Surge), CE EN61000-4-6 (CS), CE EN61000-4-8, CE, CE EN61000-6-2, CE EN61000-6-4
Safety StandardsUL 508
Warranty5 Years
Download NameFile Size
LNP-201AG-T User Manual476.67KB
LNP-201AG-T Datasheet840.07KB
