Panorama LG-IN2904 (Megalodon) 16:1 4G/5G, WiFi, & GPS Antenna Kit, 16' Cables

Panorama LG-IN2904 Antenna - 2x 4x4 MIMO 4G/5G, 6x6 MIMO WiFi, 2x GPS - 5m Cables

The LG-IN2904 Megalodon by Panorama has been developed to provide 2x 4×4 MIMO 4G/5G antenna systems covering 617-960/1427-6000 MHz within a robust low profile package. Covering global cellular bands for future-proof performance, the antenna provides effective functionality for 2x 4G Cat 18/20 and/or 5G modems. This is combined with 6x6 MIMO WiFi elements covering 2.4-7.2 GHz (Wi-Fi 6e/7) and 2 GPS (1559-1612 MHz) elements.

The antenna is designed to be panel mounted and can be fitted on a conductive or non-conductive panel. Supplied with a halogen free, flame retardant radome, the antenna is suitable for many environments and applications, including public safety and transportation. The LG-IN2904 is a kit consisting of the L2GMHM8-6-60 antenna and a complete set of 5-meter CS30 low-loss RG174 cables (compliant to UN ECE 118) terminated with male SMA connectors.

The antenna is available with a black radome which meets IK10 for vandal resistance and IP69K for Ingress protection. Check out the entire Megalodon range of antennas, your all in one antenna solution for 5G dual modem routers.

Key Features

• Omnidirectional 8x (2x 4x4 MIMO) LTE cellular antenna for 4G and 5G networks
• 617 - 960, 1427 - 4200, and 4400 - 6000 MHz LTE frequency ranges
• 6x6 MIMO WiFi 2.4/5.1 - 7.2 GHz frequency ranges
• 2 GPS or GNSS elements
• High gain from 3 to 8 dBi (peak)
• SMA male connectors
• CS30 (UN ECE R118 compliant) cables at 15-foot lengths
• Through-hole surface mount
• IP69K / IK10 compliant
• Operating temperature from -40°C to 80°C

Contact Westward Sales for the antenna available with a GNSS (1164-1189 / 1559-1612 MHz) element instead of GPS.

Megalodon Overview

When it comes to reliable performance that won’t balk in challenging environments, it’s hard to beat the Panorama LG-IN2904. Then again, a network is only as strong as its weakest link. If you want to have this level of hardware for your entire network, you can get the right devices at Westward Sales. Have a chat with one of our network experts today. We’ll help find exactly what you need to create the best network possible.
