The BSU ruggedized antenna from Panorama offers 2 dBi gain and is suitable for temporary field use or permanent installation. The antenna is built from a black, plated-brass center hub mounted on a nylon stub mast. The plastic-coated ¼ wave radiating element is fitted to the hub, and three helical elements provide the ground plane. It has an N-Type female connector to fit a long low-loss RF coaxial cable. Mast mounting hardware is included. The BSU antenna is ideal for pole mounting applications like pump stations, fixed radio terminals (FRT), and mobile or fixed repeater installations.
BSU-S1, S1 Band, 380-400 MHz frequency range
BSU-TET, TET Band, 380-430 MHz frequency range
BSU-S2, S2 Band, 410-430 MHz frequency range
BSU-S4, S4 Band, 450-470 MHz frequency range
| Technology | |
| Category | Antenna |
| Wireless | |
| Single / SISO Antennas | UHF |
| Pattern | Omnidirectional |
| Frequency Range | 380 - 470 MHz (banded) |
| UHF Frequency Bands | S1 (380 - 400 MHz), S2 (410 - 430 MHz), TET (380 - 430 MHz), S4 (450 - 470 MHz), U2 (450 - 520 MHz) |
| VSWR | <2:1 |
| Gain | 2 dBi peak gain (HCM Code H/V: 000ND00 046DE00) |
| Ground Plane | Not required |
| Power | 100 W maximum input |
| Mechanical | |
| Connector Type | N-Type female |
| Mounting | Mast mount with U-bolt |
| Color | Black |
| Ratings | |
| Operating Temperature | -40 to 80°C |
| Download Name | File Size |
| Panorama BSU Datasheet | 230.64KB |
| Image | Model | Product Name | Price | |
 | SAB-138 | Panorama SAB-138 Mast or Pole Mounting Bracket for NA, BSU, and BSV Antennas | $22.92 |
