InHand ER805 Cloud-Managed SD-WAN 5G Edge Router, 5 Ethernet Ports, Wi-Fi

InHand EdgeRouter805 Cloud Managed Router
Model: ER805
Availability: 1 Week
Standard Shipping & Handling

Choose Options

* Cellular Network:

* Ports:


Qty: Add to Cart

InHand Networks' EdgeRouter805 5G/4G SD-WAN Router with VPN, SD-WAN, Ethernet, and WiFi

InHand's ER805 (Edge Router 805) 5G and 4G edge cellular router provides high performance, convenience, and secure network access services for enterprise business networks. With various broadband services such as SD-WAN and cloud management, the ER805 5G SD router provides reliable and secure Internet access for retail stores, branch offices, smart city, health care, and IoT applications.

The ER805 adopts SD-WAN technology and offers uninterrupted data communication. Link redundancy, load balancing, bandwidth management, link failover, and other functions effectively ensure the stability of the business network and reduce the risk of network failures, thus reducing network costs and increasing productivity. In addition, the InCloud Manager, a cloud service, conveniently manages and monitors distributed devices and networks, improving efficiency and saving you time.

A comprehensive set of security protocols protect sensitive data and critical businesses from attacks and threats, creating a worry-free network. The ER805 includes access control and content filtering, multiple VPNs, digital certificates, authority management, and identity authentication. The 5G model offers extreme speed and low latency and is capable of connecting hundreds of devices and uses with safety and efficiency.

Key Hardware Features

  • Cloud-managed SD-WAN edge router for 5G networks
  • 5G Sub 6 (450 MHz to 6 GHz) 2 Gbps downlink
  • 4x4 MIMO cellular interface
  • Optional 4G LTE Cat 6 model
  • Dual SIM cards slots for redundancy and failover
  • 5 Gigabit Ethernet Ports (10/100/1000 Mbps)
  • Optional dual-band 2.4 and 5 GHz Wi-Fi (IEEE 802.11ac/a/b/g/n Wave2 MU-MIMO)
  • USB 3.0 port
  • Wall mounting
  • 9 to 48V DC input
  • Operating temperature range from -20 to 70°C

SD-WAN Router Management and Software

  • InCloud Manager for remote cloud configuration and management
  • Omnipresent and continuous Internet access using the 5G cellular network
  • SD-WAN offers a highly reliable and uninterrupted network connection
  • Zero-Touch deployment
  • Comprehensive security protection with firewall, access control, content filtering, VPN, digital certificates, authentication, ACL, and other protocols
  • Multiple real-time alarms, diagnostic tools, policy settings, and remote device control
  • Network visibility using a multi-dimensional data dashboard, statistical reporting, and traffic analytics
  • Static, RIP, OSPF, and IGMP Proxy routing protocols
  • Intelligent network management and redundancy

Need an IoT Data Plan?

Enable your ER805 with a cost-effective monthly data plan to ensure your router is ready to deploy. Select Verizon or AT&T and the data plan size from 100 MB to 5 GB. You are billed monthly; there’s no long-term contract. Plus, manage all of your fielded gateways from a single cloud-based web portal.

Purchase a SIM card from this page. It will be mailed to you in 2 to 3 business days. Then after you receive your card, sign up for a data plan at Westward Connect.

High-Performance Antenna Options

The InHand ER805 includes magnetic antennas per wireless interface. These antennas include a magnetic base. Optional dipole antennas are available for free by selecting the checkbox above. For mobile and industrial applications, consider these high-performance antennas.


ER805-NRQ3, 5G edge router (This configuration is FirstNet Ready)
ER805-NRQ3-WLAN, same as above with WiFi (This configuration is FirstNet Ready)

ER805-FQ39, Edge router with 4G LTE and CAT 6 performance
ER805-FQ39-WLAN, same as above with WiFi

In the Box

  • ER805 router
  • Power cable
  • Power adapter
  • Ethernet cable
  • Magnetic antennas (optional dipole antennas available for free upon request)
  • Panel mounting lug kit

If you want the best network, you need the best equipment. Call one of our experts to discuss your LTE router requirements. InHand Networks’ solutions are full-featured, industrial-grade, and more affordable than you might imagine. We help our clients get the most for their dollar. Let us save you time and money, too.

FirstNet built with AT&T

CategoryCellular Router
Ethernet Ports5 Gigabit (10/100/1000TX)
Cellular Interface
CarrierAT&T, T-Mobile and Verizon
SIM Holder2 SIM card slots
Networks5G Sub 6 (450 MHz to 6 GHz) with 2 Gbps downlink, 4G LTE
Network Management
Firewall FeaturesMAC/IP binding, port forwarding, Application protocol, NAT, PAT, DMZ, port mapping, virtual server, Access Control List (ACL)
IP SuitePing, traceroute, DHCP server/client, DNS relay, Dynamic domain name (DDNS), Telnet, SSH, HTTP, HTTPS, TFTP, FTP, SFTP, VLAN
VPN FeaturesIPsec, L2TP, GRE, OpenVPN, CA, PEM, PKCS12, SCEP (CA certificated)
IP SecurityLDAP, RADIUS, TACACS+, 802.11 WPA2 Enterprise, 802.1Q VLAN/QoS, 802.1X certificated, hack detection, content filtering, behavior management, hostile attack protection, filter multicast/ping probe packet, anti-DoS attack
QoSSupport protocol-based data control
Network AccessMultiple network access, 5G/4G cellular network access, ETH network access
ProtocolsIPv6, IPv4, Static IP, DHCP, PPPoE, link detection, automatic redial, SIM switchover, multiple dynamic routing and static routing,
ReliabilitySD-WAN, WAN/WiFi/cellular backup and auto-recovery, link detection, cellular link failover, dual SIM with seamless switching, fault self-recovery with embedded watchdog
MaintenanceSupport Ping, Traceroute, network packet capture tool
Cloud ProtocolsInCloud subscription service available for cloud-based management
Wi-Fi FrequenciesDual-band 2.4 and 5 GHz with 1200 Mbps transmission bandwidth
WLAN Operation ModeAP, Client
WirelessIEEE 802.11ac/a/b/g/n Wave2 MU-MIMO
Console Port1 USB 3.0
Power Consumption12 W
Input Voltage9 to 48 VDC
EnclosureMetal case with fanless cooling
Dimensions210 x 140 x 35 mm
MountingWall-mount or desktop
LED IndicatorsPower, system status, network status, WiFi operation
Antenna ConnectionSMA for cellular antennas and RP-SMA for WiFi
Operating Temperature-20° to 70°C
Storage Temperature-40° to 85°C
Humidity95% at 60°C
CertificationsCE, FCC, CCC, PTCRB, AT&T, Verizon
EMCElectromagnetic Compatibility II
Warranty3 years
