Antaira LMX-2804G-4XS (-T) 28-Port Managed Gigabit Ethernet Switch with 4 SFP Slots

Antaira LMX-2804G-4XS 28-Port Managed Ethernet Switch, Optional Extended Temperature (-T)

Antaira Technologies’ LMX-2804G-4XS is a 28-port industrial gigabit managed Ethernet switch that features 24 Gigabit Ethernet ports and 4 1Gigabit/2.5Gigabit/10Gigabit SFP+ Slots. This makes the product ideal for applications that demand high density of port connectivity, wide bandwidth and long-distance communication.

The LMX-2804G-4XS is a fully manageable Light Layer 3 Ethernet switch that is pre-loaded with a user-friendly web management console design. It supports the ring network redundancy function using the market’s open standard ITU-T G.8032 ERPS (Ethernet Ring Protection Switch) protocol that has a <50ms network recovery time. The advanced network filtering and security functions, such as IGMP, VLAN, QoS, SNMP, port lock, RMON, Modbus TCP, and 802.1X/HTTPS/SSH/SSL increase determinism and improve network management for remote SCADA systems or control networks.

The LMX-2804G-4XS is packaged in an IP30 rated rugged 1U rack-mount metal case. An extended temperature option (LMX-2802G-4XS-T) of -40 to 75°C makes it the best solution for any harsh and extreme ambient weather environment applications, such as power/utility, transportation, water wastewater treatment plant, oil/gas, and security surveillance system industries. Backed by Antaira’s 5-year warranty, you know your equipment investment will last.

Key Features

• 1U rack-mount Gigabit Ethernet with 28 total ports
• Four 1G/2.5G/10G SFP slots
• ITU-T G.8032 Ethernet Ring Protection Switch (ERPS) Protocol
• IEEE 802.1D STP (Spanning Tree Protocol), IEEE 802.1w RSTP (Rapid Spanning Tree Protocol), IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
• Static Routes, ARP
• SNMPv1/v2c/v3, RMON, Modbus TCP, and HTTP/HTTPS
• RADIUS, TACACS+, 802.1X Authentication
• ACL, IP Source Guard
• VLAN, QoS, and, SNMPv3
• IP30 Rugged Metal Case Design
• Redundant Power Input
• Fanless Operation
• Power Reverse Polarity Protection
• High EFT and ESD Protection
• Choice of standard (-10 to 65°C) or extended (-40 to 75°C) operating temperature
• 5-year warranty

Configurations

LMX-2804G-4XS,    Standard operating temperature, -10° to 65°C
LMX-2804G-4XS-T, Extended operating temperature, -40° to 75°C

In the Box

1. Quick Installation Guide
2. LMX-2804G-4XS (-T)
3. Rack Mounting Brackets and Screws
4. RJ45 to DB9 Serial Console Cable
5. Dust Cover Set

Count on the LMX-2804G-4XS rack-mount Ethernet switch for high-performance and dependability. Get more information about this switch and other networking devices by speaking with a network specialist at Westward Sales today.
