The Taoglas MB.99X bracket is purpose-built to enhance the versatility and ease of mounting for the high-performance Guardian HP Series antennas. Designed for wall, pole, or window installations, the MB.99X ensures seamless deployment in various applications, ensuring antenna installation simpler than ever and making it a reliable choice for even the most demanding environments.
Measuring under 120 mm square with a depth of just 77 mm from the mounting surface to the antenna, the MB.99X bracket ensures a lowprofile, unobtrusive installation.
The bracket is connected to the Guardian by screws and the ball joint allows the antenna to be optimally positioned for best performance, regardless of the installation type with 80 degree range of motion both vertically and horizontally.
Each MB.99X bracket comes with a mounting kit, including screws, washers, hose clamps, and suction cups. This all-in-one solution supports wall, pole, or window installations to meet the unique needs of your application.
The MA945, MA995, MA996, MA997, MA998 are antennas to use with this base.
Technology | |
Category | Wireless Accessory |
Wireless | |
Antenna Accessories | Mounting Hardware |
Mechanical | |
Dimensions | 119 x 118 x 77 mm (4.6 x 4.6 x 3 in.) |
Weight | 110 g (3.8 oz.) |
Mounting | Wall, pole, window |
Color | Black or white |
Download Name | File Size |
Taoglas MB.99X Datasheet | 560.64KB |
