Taoglas GW.11.A113 WiFi Screw Mount Dipole Hinged Antenna, 2.4 GHz

Taoglas GW.11.A113 Screw Mount Dipole Antenna, 2.4 GHz,  2.3dBi
Model: GW.11.A113
Availability: 2 - 3 Weeks or Less
FREE SHIPPING !
Qty: Add to Cart

Taoglas GW.11.A113 Bluetooth and Wireless LAN Screw Mount Antenna, SMA (M) Hinged Connector

The GW.11.A113 dipole screw mount antenna is ideal for 2.4 GHz wireless applications such as Bluetooth and Wireless LAN. At only 84mm in length, omnidirectional 2.3dBi gain across all bands ensures constant reception and transmission. The antenna structure is designed for robust handling and the housing is made with TPE giving superior environmental reliability and a quality finish. The antenna can be rotated 90 degrees on the base hinge for ease of placement.

Key Features

  • 2.4 GHz 2.3dBi Dipole Antenna
  • Hinged TPE Housing
  • Connector: IP65 at SMA (M)
  • Length: 84 mm
  • ROHS Compliant
Technology
CategoryAntenna
Wireless
Single / SISO AntennasWiFi/Bluetooth/Zigbee
PatternOmnidirectional
Mechanical
Connector TypeSMA (male)
Dimensions84 mm length
MountingTerminal mount with rotatable hinge for optimal reception
Ratings
RoHS CompliantYes
CertificationsIP65 rated (water and dust proof)
Download NameFile Size
Taoglas GW.11.A113 Datasheet916.01KB
