Taoglas AGPSF.36C Embedded Active GPS L1/L2 Stacked Patch Antenna

Taoglas AGPSF.36C Active GPS L1/L2 Low Profile Stacked Patch Antenna, I-PEX MHF I
Model: AGPSF.36C.07.0100C
Availability: 2 - 3 Weeks or Less
FREE SHIPPING !
Qty: Add to Cart

Taoglas AGPSF.36C Active GPS L1/L2 Low Profile Stacked Patch Antenna, I-PEX MHF I

The Taoglas AGPSF.36C is an embedded active GPS L1/L2 stacked patch antenna. This compact antenna exhibits excellent radiation patterns on both L1 and L2 bands, and with a low noise figure to preserve signal quality helps minimize time to first fix. It also features excellent out-of-band rejection to prevent out-of-band signals from overdriving or damaging its LNAs. It is a high performance, economical solution for the highest accuracy centimeter-level tracking applications. Typical applications include: UAVs and Robotics, Transportation, Autonomous Vehicles, Marine, Agriculture, and Navigation.

The Taoglas AGPSF.36C features very tight Phase Centre Offset (PSO) at just ±2cm at the L1 Band and ±5cm at the L2. The precision of antenna phase center directly affects the accuracy of GNSS positioning systems and can ensure that the accuracy of the receiver really is cm level.

This antenna has been tuned and tested on a 70 X 70 mm ground plane, working at GPS L1, 1575.42 MHz and L2, 1227.6 MHz, with a 2 stage LNA ensuring good signal strength. It can operate with an input voltage ranging from 1.8 to 5 volts.

Key Features of the Taoglas AGPSF.36C Antenna

  • Embedded Active GPS L1/L2 Stacked Patch Antenna
  • GPS L1 & L2 Band Operation
  • Low Noise Figure
  • Excellent Out-Of-Band Rejection
  • Low Axial Ratio
  • 2 Stage LNA and SAW filter
  • Cable : 100 mm of Ø1.37 coaxial
  • Connector: I-PEX MHF I
  • Dimensions: 35 x 35 x 11.1 mm
  • RoHS and REACH Compliant
Technology
CategoryAntenna
Wireless
Single / SISO AntennasGPS
PatternOmnidirectional
Gain2 stage LNA with SAW filter
PolarizationLow axial ratio
Antenna EfficiencyExcellent out-of-band rejection
Antenna TypeEmbedded active GPS (L1/L2 band operation) stacked patch antenna
Mechanical
Cabling100 mm long x Ø1.37 mm coaxial
Connector TypeI-PEX MHF I (U.FL compatible)
Dimensions35 x 35 x 11.1 mm
Download NameFile Size
Taoglas AGPSF.36C.07.0100C Datasheet1.09MB
