The SMW-305 antenna features 3 antenna elements in one radome. The unique feature of this model is that cable 1 is extremely widebanded and can cover LTE at 700 MHz as well as the established 850/1900 GSM/CDMA bands, 1.7/2.1 AWS bands and WiMAX 2.5 all on a single board. The antenna also covers 2.4/5 dual-band WiFi on the second antenna element which can also be used for other specialized applications such as Public Safety coverage at 4.9 GHz, or DSRC at 5.9 GHz. The third element covers GPS at 1575 MHz.
This antenna is popular for fleet management systems that require high speed data transmissions. It is enclosed in a weatherproof black or white radome, and supplied with all mounting hardware and a sealing gasket
SMW-305-3C3C2C-BLK-180, 3-in-1 combo Antenna, surface mount, black radome
SMW-305-3C3C2C-WHT-180, Same as above with white radome
MGW-305-3C3C2C-BLK-180, 3-in-1 combo Antenna, magnet mount, black radome
MGW-305-3C3C2C-WHT-180, Same as above with white radome
Technology | |
Type | Antenna |
Wireless | |
Combination / MIMO Antennas | 3:1 (LTE, WiFi, GPS) |
Pattern | Omnidirectional |
Cellular Frequencies | 694 - 894 and 1700 - 2700 MHz |
VSWR | 2:1 max over range |
Gain | 2 - 5 dBi |
Impedance | 50 ohms |
Power | 10 W |
Interfaces | |
GPS | Yes |
Mechanical | |
Cabling | 15 ft. low loss |
Connector Type | SMA male |
Dimensions | 4.2" diameter x 3.2" high (add 1/2" for magnet base) |
Mounting | Permanent or magnet |
Shock / Vibration | IEEE1478, EN 61373, MIL-810G, TIA 329.2-C |
Color | Black or white |
Material | Plastic |
Ratings | |
Operating Temperature | -40° to +80° C |
Certifications | IP67 |
Warranty | 2 years |
Download Name | File Size |
Mobile Mark SMW-305 Datasheet | 305.87KB |
