Cel-Fi PD2030 and PD2130 3-Way Power Combiner and Splitter, SMA or N-Type

Cel-Fi PD2030 3-Way Power Combiner and Splitter, SMA or N-Type Connectors
Model: PD2x30
Availability: IN STOCK
FREE SHIPPING !

Choose Options


Connectors:

Qty: Add to Cart

Cel-Fi PD2030 and PD2130 3-Way Power Splitter and Combiner with SMA or N-Type Connectors

The Cel-Fi PD2030 and PD2130 from Nexity are 3-way RF power splitters and combiners. They support wireless frequencies bands from 698 to 2700 MHz and handle input power levels up to 40 watts. Choose from N-Type female or SMA female connectors. The PD2030 and PD2130 are perfect for a variety of wireless applications. We recommend one with a Cel-FI cellular booster kit to split the LTE signal from a GO or Quatro booster to multiple source antennas.

Key Features

  • 3-way power splitter and combiner
  • Supports 698 to 2700 MHz frequencies
  • Choice of N-Type or SMA female connectors
  • 50 Ohm coaxial
  • Low insertion loss and excellent VSWR
  • High isolation (30 dB) between ports
  • Input power level up to 40 watts
  • Rugged metal case

Configurations

PD2030, 3-way splitter and combiner with three N-Type female connectors
PD2130, same as above with SMA female connectors

Technology
TypeWireless Accessories
Wireless
Cellular Frequencies698 - 2700 MHz
VSWR1.3 : 1 (input) and 1.25 : 1 (output)
Impedance50 Ohms
Antenna AccessoriesSplitters and Combiners
Power40 watts
Mechanical
Connector Type4 SMA female or N-Type female
Dimensions2.98 x 2.98 x 0.88" (75.7 x 75.7 x 22.2 mm)
Weight292 g
Ratings
Operating Temperature-65°C to 85°C
Humidity5% to 95%, noncondensing
RoHS CompliantYes
Tags: PD2130, PD2030
