Antaira ANT-MGNBASE-1.5M Magnetic Stand for Dipole Antennas with 5' (1.5m) Cable

ANT-MGNBASE-1.5M.magnetic stand for antenna with 5 feet of cable
Model: ANT-MGNBASE-1.5M
Availability: IN STOCK
FREE SHIPPING !
Qty: Add to Cart

Antaira ANT-MGNBASE-1.5M Antenna Extension with Magnetic Base, 5-foot Cable, and RP-SMA Connectors

Antaira Technologies’ ANT-MGNBASE-1.5M extends the working distance from a radio to the antenna by five feet (1.5 meters).  It features a strong magnetic base that secures to metal panels and brackets.  The base is heavy enough to hold the antenna upright if the surface is non-metallic.  It’s suited for indoor and outdoor applications.  It is compliant with all types of wireless antennas with operating frequencies up to 18 GHz.  It supports LTE, GSM, ISM, WiFi and WiMax networks (IEEE 802.11N/AC/G/A/B, 900 MHz, 2.4 GHz, and 5 GHz).

The reverse polarity SMA (RP-SMA) female connector on the base mates to antennas that have a male RP-SMA jack.  Whereas, the RP-SMA male connector on the cable fits radios with a female RP-SMA connector.  Both have right-hand threads.

Key Features

  • Secure magnetic base
  • Gold-plated brass connector body with a nickel-plated copper crimp ferrule
  • Gold-plated beryllium copper center contact
  • RP-SMA female base connector and RP-SM male cable connector
  • Double-shielded 5-foot cable with PTFE insulation for low signal-loss and protection
  • Operating temperature range: -40° to 65°C
  • 2-year warranty

The ANT-MGNBASE-1.5M fits several dipole antennas offered by Westward Sales.  Contact us to see if this antenna accessory is right or your wireless project.

Technology
TypeAntenna
Wireless
Frequency RangeUp to 18 GHz
Impedance50 Ω
Antenna AccessoriesMounting Hardware
Power
FrequencyUp to 18 GHz
Mechanical
Connector TypeRP-SMA female (cable) and RP-SMA male (base) with right-hand threads.
Ratings
Operating Temperature-40 to 65° C
RoHS CompliantYes
Warranty2 years
Download NameFile Size
ANT-MGNBASE Datasheet360.4KB
