The TEG-S16Dg GREENnet Desktop Switch provides high bandwidth performance, ease of use, and reliability. 16 gigabit ports provide high-speed network connections to devices and a 32 Gbps switching capacity allows data traffic to flow smoothly, reducing traffic bottlenecks.
Embedded GREENnet technology provides cost savings and reduces power consumption by up to 70%, by limiting port power consumption during periods of low link utilization. GREENnet technology works right out of the box with no management requirement.
With a compact and sturdy metal housing design this switch is well-suited for desktop installations. Its fanless design is perfect for quiet environments that require silent operation. Plug and Play this switch for reliable high-speed network connectivity.
| Technology | |
| Category | Ethernet Switch |
| Total Ports | 16 |
| Ethernet Ports | 16 Gigabit ports |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az |
| Transfer Rate | Ethernet: 10 Mbps / 20 Mbps (half / full-duplex), Fast Ethernet: 100 Mbps / 200 Mbps (half / full-duplex), Gigabit Ethernet: 2000 Mbps (full-duplex) |
| Jumbo Frame Support | 10 KB |
| Power | |
| Power Consumption | 10.1 W |
| Input Connection | 100 – 240V AC, 50/60Hz, internal power |
| Mechanical | |
| Mounting | Desktop, Rackmount kit optional |
| LED Indicators | Power, link, and activity |
| Weight | 1.1 kg (2.4 lbs.) |
| Dimensions | 280 x 125.8 x 44 mm (11 x 5 x 1.7 in.) |
| Ratings | |
| Operating Temperature | 0° - 40° C (32° - 104° F) |
| Humidity | 90% non-condensing |
| Certifications | FCC, CE |
| Warranty | Lifetime |
