The WCM.01.0151 antenna is the smallest RP-SMA (M) external antenna on the market, fitting into spaces no other traditional monopole, dipole or rubber ducky antenna can go. A unique PIFA design ensures omnidirectional gain across 2.4 GHz to 2.5 GHz ensuring constant reception and transmission to make it a great WiFi antenna for 2.4 GHz WiFi and Bluetooth applications. Typical Applications include: Application Points, Routers, IoT M2M devices, and Smart Home. This antenna features greater than 60% efficiency when connected directly to the ground plane of the device.
This antenna comes with an RP SMA (M) to be compatible with most WiFi applications and routers. The WCM.01.0151 antenna is also IP67 water resistant. The ideal position for the antenna to radiate is mounted clear of metal housings. It is available in black or white. An SMA (M) version is also available, WCM.01.0111.
WCM.01.0151, 2.4 GHz Button Antenna in black
WCM.01.0151W, Same as above in white
| Technology | |
| Category | Antenna |
| Wireless | |
| Single / SISO Antennas | WiFi | Bluetooth / Zigbee |
| Pattern | Omnidirectional |
| Wi-Fi Frequencies | 2400 - 2500 MHz |
| Antenna Efficiency | >60% |
| Mechanical | |
| Connector Type | RP-SMA (male) |
| Dimensions | 19.8 x 14.3 x 16.4 mm |
| Color | Black |
| Ratings | |
| Certifications | IP67 rated (water and dust proof) |
| Download Name | File Size |
| Taoglas WCM.01.0151 Datasheet for the black antenna | 3.83MB |
| Taoglas WCM.01.0151W Datasheet for the white antenna | 3.94MB |
