Parsec PTA3BCLWG (Border Collie) 3-in-1 5G Cell, WiFi, and GPS Antenna

Parsec PTA3BCLWG 3-in-1 5G Cellular Antenna (600-6000 MHz) with Wi-Fi and GPS

The PTA3BCLWG (Border Collie) is a high-performance, omnidirectional antenna designed for 5G cellular networks. It is ideal for intelligent transportation, emergency and fleet vehicles, remote video monitoring, and mobile applications where quality communication is critical. The PTA3BCLWG combines one 5G LTE, one WiFi, and GPS antennas into a low-profile, waterproof radome. It operates over the 600 MHz to 6 GHz frequency range, supporting all bands from North American mobile operators. The PTA3BCLWG, with Cat 18 performance, features superior efficiency and isolation to boost poor signals and increase download and upload data rates. In addition, it pairs well with the latest cellular routers, such as those from Ericsson Cradlepoint.

Not only is the PTA3BCLWG’s performance remarkable, but it is equally tough. The IP67-rated dome stands up to harsh environments and is impervious to impact, severe temperature, water, and corrosion. The antenna assembly requires a single mounting hole and installs flush to a surface such as a vehicle rooftop or electronic enclosure. The RF cables pass through a hollow bolt on the bottom of the antenna and are hidden from view. With top-shelf construction, you can count on the PTA3BCLWG for a lifetime of operation.

This antenna comes standard with 20 ft. LSR200 low loss cables and TNC male connectors.

Key Features

• Omnidirectional multi-antenna with Cell, WiFi, and GPS
• 5G Cellular covering 617-894 MHz, 1710-2700 MHz, 3400-3800 MHz, and 5150-5925 MHz
• WiFi covering 2400-2483.5 MHz, 4900-5900 MHz
• Rugged IP67 rated radome in black or white color
• 5 watts maximum input power
• High efficiency up to 80%, no ground plane required
• 8 dBi peak gain
• Operating temperature from -40 to 85°C
• LSR200 low loss cables
• Surface mount with 1” diameter x 0.75” long bolt

Network pros go with antennas from Parsec Technologies for their wireless networks. Connecting a Parsec antenna to a cellular router or gateway enhances signal quality, data bandwidth, and efficiency. Get the PTA3BCLWG for your network – one of the most durable and trusted 5G antennas on the market. Speak with a Westward Sales wireless specialist today to see if the PTA3BCLWG is best for your application.
