Mobile Mark CVWG-WB2 2:1 Compact Covert 5G/LTE, GPS Antenna (617-7200 MHz)

Mobile Mark CVWG-WB2 2-in-1 Compact Covert 5G/LTE & GPS Antenna, Adhesive Mount

The CVWG-WB2 is a 2-cable covert and compact antenna covering 5G/LTE from 617 - 960 MHz & 1700 - 7200 MHz and GPS. It is also compatible with WiFi 6E. This 5G ready antenna makes it possible to connect to any of the current or planned cellular frequency bands that reside within that range. Although this antenna was designed for cellular, it could also be used for Wi-Fi 6e covering the 2.4, 5 and 6 GHz band.

This 5G ready solution can be used in many environments including vehicles, NEMA boxes, and outside sensing locations. This antenna can be mounted to the outside of a metallic container. It can also be mounted to either the inside or the outside of a non-metallic container such as a plastic or fiberglass NEMA box.

The CVWG-WB2 is an excellent choice for 5G ready mobile hotspots or Industrial IoT networks requiring a discreet, low profile antenna solution. This antenna can be used indoors or outdoors and can be mounted with double sided tape. This rugged antenna meets industry and military Shock and Vibration standards.

Key Features

• 5G/LTE coverage 617 - 960 & 1700 - 7200 MHz, 2.5 dBi gain
• GPS 1575 MHz
• Backwards compatible for 4G LTE
• Wi-Fi 6E compatible
• Adhesive mount
• Shock & vibration: IEEE-1478, EN61373, and MIL-810G
• Dimensions: 5.5 x 1.59 x 0.71 inches
• Cables: 15 feet, LL-195 for LTE, RG-174 for GPS
• Connectors: SMA (M)
