Manage your wireless network from anywhere in the world with the Nuclias Cloud Wi-Fi 6 DBA-X2830P indoor access point. Designed to give you the latest technology and efficiency in any setup, it’s ideal for SMB, retailers, hospitality, campuses, and managed service providers. Deliver high-combined data rates of up to 3,600 Mbps over 2 dedicated wireless bands with the latest WPA3 wireless security.
It is deployed as a premanaged, zero-configuration access point (AP) controlled through the D-Link Nuclias Cloud. It is designed specifically for enterprise environments. Featuring 802.11ax Wi-Fi 6 concurrent on both 2.4 GHz and 5 GHz bands, the DBA-X2830P offers high combined data rates to wireless clients. It provides lightning-fast access to bandwidth-intensive applications such as data, voice and video streaming, even in highly congested environments. It supports up to eight VLANs per band, allowing multiple SSIDs to segment users. It features wireless client isolation, which limits direct client-to-client communication for added privacy. Moreover, Network Access Protection (NAP) allows multiple levels of network access to be defined based on a client’s needs.
It can be ceiling-mounted, wall-mounted, or placed on a desk.It features include PoE (Power over Ethernet) for simplified installation, support for high-density environments, and advanced management tools like zero-touch deployment and multi-site control. MU-MIMO is the ultimate weapon in handling congestion by being able to support more simultaneous streams of data. Your Access Point can serve more people at the same time. That’s less waiting time all round. It features include PoE (Power over Ethernet) for simplified installation and advanced management tools like zero-touch deployment and multi-site control. MU-MIMO is the ultimate weapon in handling congestion by being able to support more simultaneous streams of data. Your Access Point can serve more people at the same time. That’s less waiting time all round. No need to run extra power lines, and no-hassle configuration thanks to the Nuclias Cloud management and auto-configuration options. It is perfect for advanced installations where technicians may not be readily available.
Complete control comes as standard with the DBA-X2830P. Combined with the Nuclias Cloud management software, a variety of the latest in network security and management tools are at your fingertips. You can rest assured that the best of the best are hard at work keeping your network better protected and hitch free.
Nuclias Cloud makes remote network management a breeze. All your management software and hardware is hosted in the Nuclias Cloud and accessible from any laptop or mobile. Businesses of any size and level of IT resources can reap all the benefits of Cloud Networking to boost productivity and enhance competitiveness. The DBA-X2830P comes with a 1-year license included. An additional 1, 3, or 5 year license can be purchased thereafter.
![]() | 100% Cloud ManagedCompatible with Nuclias Cloud solution, this product is ideal for business networks of any size. Deploy networks easily with zero-touch deployments and remote management from a web browser or the free app.
Quick VPNNuclias enables easy P2P VPN tunneling for better business privacy and remote working. Rapidly establish your VPN via the Nuclias dashboard for more secure connections.
Enhanced SecurityCommunications between Nuclias devices and the cloud are secured with end-to-end SSL encryption. Features like WPA3 encryption, MAC address filtering, and support for RADIUS servers help protect the network from unauthorized access.
Simplified Management PoliciesNuclias Cloud empowers you with essential tools, such as Content Filters, Firewalls or Application Control. Define your policies as necessary, and then roll them out across the entire network for greater network-wide consistency. |
| Technology | |
| Category | WiFi Access Point |
| Standards | IEEE 802.11a/b/n/g/ac/ax, IEEE 802.3az, IEEE 802.3at, IEEE 802.3i/u/ab, IEEE 802.3x |
| Network Management | |
| System Configuration | CE Class B, FCC Class B, UL-2043, IC Class B |
| Wireless | |
| Wi-Fi Frequencies | Power/Cloud, 2.4 GHz, 5 GHz, LAN 1, LAN 2 |
| Antenna Type | Built-in 4x4 MU-MIMO omnidirectional antennas |
| Encryption Security | WPA2/WPA3 |
| Interfaces | |
| LAN Ports | 1 x 10/100/1000/2500 Mbps Ethernet Port, 1 x 10/100/1000 Mbps Ethernet Port |
| Console Port | 2.4 GHz (20 dBm), 5 GHz (20 dBm) |
| Power | |
| Power Consumption | IEEE 802.3at Power over Ethernet (PoE) on LAN 1, Power adapter: 12 V DC, 2.5 A |
| Input Connection | RJ45 |
| Mechanical | |
| Mounting | 935 g (2.06 lbs.) |
| LED Indicators | Power/Cloud, 2.4 GHz, 5 GHz, LAN 1, LAN 2 |
| Weight | 22.45 x 22.39 x 5 cm (8.83 x 8.81 x 1.97 in) |
| Dimensions | PoE: 25.1 W, Power adapter: 27 W |
| Ratings | |
| Operating Temperature | 0 - 40° C (32° F - 104° F) |
| Storage Temperature | -20 - 65° C (-4° F - 149° F) |
| Humidity | 10 - 90% non-condensing |
| Certifications | CE Class B, FCC Class B, UL-2043, IC Class B |
| MTBF | 485,000 hours |
