CyberPower BP48VP2U01 UPS Systems Extended Battery Module, 48 V/60 A Output

New CyberPower BP48VP2U01 Rack/Tower UPS Battery Module, 48V/60A, 12V/7AH
Model: BP48VP2U01
Availability: 1 Week
Standard Shipping & Handling
Qty: Add to Cart

CyberPower BP48VP2U01 Rack/Tower UPS Extended Battery Module (EBM)

The CyberPower BP48VP2U01 is a rack/tower convertible Extended Battery Module (EBM) that extends battery runtimes during power outages and is designed for the following UPS systems: PR750RTXL2UC and PR1000RTXL2UC. The DC plug-and-play power connectors allow for daisy-chaining additional EBMs to the UPS system. The EBM also has a built-in battery charger, providing Fast Charge Technology to quickly restore the backup power supply to full capacity.

This EBM takes 2U of rack space and can be installed in either a rack or tower configuration to match the UPS form factor. Battery equalization technology improves battery life, and toolless battery panel access makes battery replacement fast and simple.

The BP48VP2U01 comes with a 3-year lifetime limited warranty.

Key Features

  • 48 V/60 A Output
  • Fast Charge Technology
  • 2U Rack/Tower Form Factor
  • Toolless Battery Panel Access
  • 3-Year Limited Warranty

In the Box

  1. Extended Battery Module
  2. Faceplate
  3. User Manual
  4. Rack Mounting Kit
  5. Tower Mounting Kit
  6. BM Cable
  7. (2) IEC C13-C14 Cables

CyberPower manufactures professional grade UPSs to satisfy a wide range of battery backup requirements. To find out which CyberPower UPS model is best for your project, contact Westward Sales today!

Technology
CategoryExtended Battery Module
Battery
Battery TypeSealed Lead-Acid Battery
Recharge Time6 Hours
Power
Output Voltage48 V
Mechanical
Enclosure2U Rack or tower
ColorBlack
MaterialMetal
Weight55.8 lbs.
Dimensions17.1 x 3.4 x 16.2 in
Ratings
Operating Temperature32 - 104 °F (0 - 40 °C)
Humidity0% to 95% non-condensing
RoHS CompliantYes
CertificationsCE, RCM, UL1778, cUL, FCC Class B, VCCI
Warranty3-year
