Black Box KVXHP-400 4K DisplayPort Quad-Head KVM CATx or Fiber Extender

Black Box KVXHP-400 High Performance KVMA Extender with DisplayPort 1.2 MST Technology

The KVXHP-400 Extender is a high-performance KVMA (keyboard, video, mouse, audio) extender. Using DisplayPort 1.2 (Multi-Stream Transport) technology it supports up to four external displays transmitted over a single cable. HD video, USB 2.0 (HID), and audio are all transmitted over a single CATx or Fiber cable. Whether your requirements are CATx or fiber, the KVXHP-400 is equipped to handle both interfaces providing a single solution for all use cases. Developed for enterprise organizations and high-pressure control rooms, it combines the simplicity of true plug-and-play and high-performance 4K KVM extension. In a point-to-point configuration, this quad-head model enables you to use four DisplayPort monitors, USB keyboard/mouse/ other devices, speaker and microphone to operate a remote computer, server, or other IT device.

The KVXHP-400 supports four external MST enabled DisplayPort monitors with resolutions up to 1920x1200 at 60 Hz using 8 bits per color and 4:4:4 chroma sampling, provides high-quality audio, EDID management, and Emulated USB 2.0.

Key Features

• Quad-Head video at HD60 via DisplayPort 1.2 MST (Multi-Stream Technology)
• Point to point extension up to 328 ft (100m) over CATx or 2.5 miles (4km) over fiber cable
• CATx or Fiber flexibility
• True USB emulation supports the most advanced keyboards and mice
• Intelligent EDID management reduces monitor compatibility issues
• Digital / Analog audio
• 4 x Tri-color connection status LEDs
• Single or Dual-Head models also available

In the Box

1. (1) Transmitter
2. (1) Receiver
3. (2) 12V, 1.5A Power Supply
4. (1) DisplayPort Cables M/M, 1.8m (6 ft.)
5. (1) USB Type A to B Cables, M/M, 1.8m (6 ft.)
6. (1) 3.5mm Audio Cable, MM, 3m (10 ft.)
7. (2) US Power Cords

Notes

1. For Fiber connectivity, please order the SFP's separately.
2. MST enabled monitors or MST hub required.
3. If the application requires 2 or more monitors in MST mode (including using an MST hub), the monitors must be HD and not 4K or the application will not function properly.
