Black Box EME1D1-005-R2 AlertWerks DC Voltage Sensor

Black Box EME1D1-005-R2 AlertWerks Isolated Digital Voltmeter

The EME1D1-005-R2 is an isolated digital DC volt meter which can be used to monitor and log DC voltage readings from batteries and other equipment. It can also be used to integrate third-party sensors that have DC voltage output.

The Isolated Digital Voltmeter can be used to create custom data collection systems. The user can input a DC voltage range from -60 to 0 volts or from 0 to +60 volts DC.

The sensor incorporates an isolated ground for better safety and protection against overvoltages and short circuits. Readings are available in both an absolute value and a percentage of full scale. Full scale is user programmable with both the base and top voltages from -60 to +60 volts DC. All readings are given with a resolution of one decimal point.

The EME1D1-005-R2 can measure DC voltage in the range 0 to 60 volts or -60 to 0 volts, and the web interface is both flexible and easy to use.

Key Features of the EME1D1-005-R2

• Enables you to integrate a custom sensor with the ServSensor while retaining all the features of the standard sensors
• Powered by the Environmental Monitoring System Hub no external power needed
• User programmable with both the base and top voltage from 0 to 60 volts
• Features isolation ground for better safety and circuit protection
• Readings are available in both raw data and as a percentage of full scale
• Measurement range: High Warning, Low Warning, High Critical, Low Critical
• Disconnect alarm
• Works with all ServSensors
